Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 160mm -
Fork Fox Float 34
-
Groupset X9, X7 -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
2014 Range carbon 27.5 frame 160 mm travel
Suspension Fork
Fox 34 Float Evolution 27.5 160 O/C CTD 15mm
Rear Shock
Fox Float Evolution CTD LV high volume
Drivetrain
Rear Derailleur
SRAM X-9 Type 2 long cage
Front Derailleur
SRAM X-7 10 speed
Shift Levers
Jagwire LEX housing
Cassette
SRAM PG 1030 11-36 T cassette 10 speed
Crank
Race Face Chester 36/22T (no guard) PF BB 92
Bottom Bracket
N/A
Chain
SRAM 10 speed PC 1031 chain
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
Joytec alloy MTB w/disc 15 mm axle
Rear Hub
Joytec 142 x 12 12 mm through hole disc
Rims
Sun Inferno 27 27.5 trail / AM rim
Tires
Schwalbe Hans Damph 27.5x2.35
Brakes
Brakes
Avid Elixer 5 hydraulic brake w/ 160 mm rotor
Brake Levers
N/A
Disk Rotors
N/A
Cockpit
Stem
Race Face Chester stem
Handlebar
Race Face Chester 25 mm rise alloy 740 mm
Grips
Norco design lock on grip
Headset
FSA Orbit C-40-ACB No.42/ACB integrated
Seat
Saddle
WTB Volt Sport saddle
Seatpost
Norco alloy 2014 double bolt seatpost 30.9 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.45 mm | 1.41 mm | 1.36 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm | 344 mm |
| Front Center | 699 mm | 722 mm | 746 mm | 770 mm |
| Rake | 38 mm | 39 mm | 39 mm | 39 mm |
| Trail | 117 mm | 116 mm | 116 mm | 116 mm |
| Stack | 600 mm | 610 mm | 619 mm | 628 mm |
| Reach | 402 mm | 420 mm | 440 mm | 461 mm |
| Top Tube Length | 577 mm | 603 mm | 630 mm | 657 mm |
| Seat Tube Angle | 73.6 ° | 73.2 ° | 72.8 ° | 72.5 ° |
| Seat Tube Length | 405 mm | 435 mm | 470 mm | 510 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 428 mm | 432 mm | 436 mm | 440 mm |
| Wheelbase | 1127 mm | 1154 mm | 1182 mm | 1211 mm |
| Bottom Bracket Drop | 10 mm | 10 mm | 10 mm | 10 mm |
| Standover Height | 755 mm | 756 mm | 754 mm | 753 mm |
| Front Travel | 160 mm | 160 mm | 160 mm | 160 mm |
| Rear Travel | 160 mm | 160 mm | 160 mm | 160 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Range Carbon 7.2 is a Norco Range model. There are 82 bikes that carry this model name. You can easily view all of the Norco Range bikes models from 2014, here.
Model range prices
The most economical model, the Norco Range Alloy 7.2 2014 has a starting price of 2409$. Norco Range Carbon LE 2014 on the other hand is the most expensive at 7345$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Enduro bikes average price
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Norco released this model in 2014, its price was 3630$. Doing a quick comparison, we notice that Range Carbon 7.2 price is 0.86% higher than the average cost of an Enduro bike.
Range Carbon 7.2 components
Fork
This bike has the Fox Float 34 fork installed. The fork’s travel is 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The Range Carbon 7.2 has a rear shock with a travel of 160mm. The model Fox Float Evolution CTD LV high volume is the one installed in this bike. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on Range Carbon 7.2 are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Range Carbon 7.2 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Norco Range Carbon 7.2 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
