Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Wheels 29" -
Travel Front 160mm -
Travel Rear 160mm -
Suspension Full
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
2011 Range frame (160 mm travel) Syntace dropouts
Rear Shock
FOX RP 23 w/ high volume air sleeve
Cockpit
Headset
Cane Creek 40 ZS ( for tapered HT and fork)
Seat
Seatpost
Rockshox Reverb adjustable seatpost 30.9 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.47 mm | 1.43 mm | 1.39 mm | 1.36 mm |
| Bottom Bracket Height | 360 mm | 360 mm | 360 mm | 360 mm | 360 mm |
| Front Center | 677 mm | 697 mm | 719 mm | 739 mm | 761 mm |
| Rake | 56 mm | 56 mm | 56 mm | 56 mm | 56 mm |
| Trail | 102 mm | 102 mm | 102 mm | 102 mm | 102 mm |
| Stack | 572 mm | 572 mm | 581 mm | 590 mm | 599 mm |
| Reach | 369 mm | 389 mm | 406 mm | 423 mm | 440 mm |
| Top Tube Length | 545 mm | 565 mm | 585 mm | 605 mm | 625 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 395 mm | 395 mm | 430 mm | 470 mm | 510 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 120 mm | 120 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1109 mm | 1129 mm | 1150 mm | 1171 mm | 1192 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 780 mm | 765 mm | 765 mm | 773 mm | 785 mm |
| Front Travel | 160 mm | 160 mm | 160 mm | 160 mm | 160 mm |
| Rear Travel | 160 mm | 160 mm | 160 mm | 160 mm | 160 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Range LE Framekit belongs to the Norco Range model. Norco launched 82 frames of this model so far. You can easily view all of the Norco Range frames models from 2012, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Enduro frames average price
Our math shows that the average cost of a dependable Enduro frame is 1895$. However, this doesn’t mean that if you spend less money on an Enduro frame, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your frame, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2012 for 2300$. Doing a quick comparison, we notice that Range LE Framekit price is 21.37% more expensive than the average cost of an Enduro frame.
Overview of components
Rear Shock
The shock that’s installed on this frame is FOX RP 23 w/ high volume air sleeve, with a travel distance of 160mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Sizes
This frame is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Norco Range LE Framekit includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
