Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 180mm -
Travel Rear 170mm -
Fork Fox Factory Float 38
-
Groupset XTR, XT -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Integrated, Removable, 900Wh, 720Wh and 540Wh Options -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 166cm
MD
163cm - 175cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Front Triangle and Seatstay, Aluminum Chainstay, 170mm Travel, UDH, Hangerless Interface Compatible, Ride Aligned™
Suspension Fork
Fox Factory FLOAT 38, GRIP 2, HSC/LSC, HSR/LSR, 180mm, 44mm Offset, E-Rated
Rear Shock
Fox Factory DHX2, Coil Spring, HSC/LSC, HSR/LSR, Custom Tune, 230x62.5mm, 400lb/in (S), 450lb/in (M), 500lb/in (L), 550lb/in (XL)
Drivetrain
Rear Derailleur
Shimano XTR M9100
Shift Levers
Shimano XT Sl-M8100 I-Spec EV
Cassette
Shimano SLX CS-M8700, 10-51T, 12 Speed
Crank
Shimano FC-M8150 E-MTB, 34T, 165mm
Chain
Shimano SLX CN-M7100
Wheels
Front Hub
DT Swiss 350H, 15x110mm Boost, Center Lock
Rear Hub
DT Swiss 350H, 12x148mm Boost, Micro Spline, Center Lock
Rims
DT Swiss E 1700 Hybrid E-Rated Wheelset, 29"
Tires
Front: Maxxis Assegai 2.5" 3C MaxxGrip/DD/TR/WT, Rear: Maxxis Assegai 2.5" 3C MaxxGrip/DD/TR/WT
Brakes
Brakes
Front: Shimano XT BR-M8120, 4 Piston Metallic Pads, Ice Tech, Rear: Shimano XT BR-M8120, 4 Piston Metallic Pads, Ice Tech
Cockpit
Stem
CNC Alloy, 40mm Length, 35mm Clamp
Handlebar
Deity Ridgeline, 800mm, 25mm Rise
Grips
DMR DeathGrip A20 Soft, Thin (S, M), Thick (L, XL)
Headset
FSA No.55R-1, Sealed Bearing
Seat
Saddle
Ergon SM-10 E-Mountain Sport
Seatpost
OneUp Adjustable Dropper, 34.9mm, 120mm (S), 150mm (M), 170mm (L), 210mm (XL)
Motor & Battery
Motor
Shimano STEPS EP8
Battery
Integrated, Removable, 900Wh, 720Wh and 540Wh Options
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.43 mm | 1.35 mm | 1.29 mm |
| Bottom Bracket Height | 356 mm | 356 mm | 356 mm | 356 mm |
| Front Center | 771 mm | 806 mm | 840 mm | 875 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 140 mm | 140 mm | 140 mm | 140 mm |
| Stack | 617 mm | 627 mm | 636 mm | 645 mm |
| Reach | 410 mm | 440 mm | 470 mm | 500 mm |
| Top Tube Length | 564 mm | 593 mm | 620 mm | 649 mm |
| Seat Tube Angle | 76.2 ° | 76.5 ° | 76.9 ° | 77.2 ° |
| Seat Tube Length | 395 mm | 415 mm | 440 mm | 455 mm |
| Head Tube Angle | 63 ° | 63 ° | 63 ° | 63 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 457 mm | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1227 mm | 1262 mm | 1296 mm | 1331 mm |
| Bottom Bracket Drop | 19 mm | 19 mm | 19 mm | 19 mm |
| Standover Height | 702 mm | 704 mm | 721 mm | 732 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 154 cm | 163 cm | 172 cm | 181 cm |
| Rider Max Height | 166 cm | 175 cm | 184 cm | 191 cm |
Model Overview
Range VLT C1 completes the Norco E Range model. 14 e-bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Norco Range VLT A2 2023 is the most economical model, with a starting price of 6398$. Norco Range VLT C1 2023 on the other hand costs 9898$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro e-bikes
If you want to purchase a solid Enduro e-bike, it is important to know that the average cost is 4785$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
When Norco released this model in 2023, its price was 9898$. If we compare this with the average Enduro e-bike cost we notice that the price is 106.85% more expensive.
Overview of components
Fork
Norco Range VLT C1 2023 e-bike is equipped with the Fox Factory Float 38 fork, and has 180mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the Fox Factory DHX2 rear shock model, which has a travel of 170mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
The Range VLT C1 2023 e-bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Range VLT C1 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 154 cm – 191 cm (5.05 ft – 6.27 ft). In short, you can easily find one that suits you.
Dropper post
The Norco model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
