Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 180mm -
Travel Rear 170mm -
Fork Fox Performance Elite Float 36
-
Groupset NX Eagle, SRAM -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery In-Tube Battery, 630Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon 27.5, 170mm Travel, M/L/XL
Suspension Fork
Fox 36 Performance Elite, GRIP 2, 180mm Travel
Rear Shock
Fox Performance Elite DHX2, LSC, HSC, Coil Spring, M 500lb, L 550lb, XL 600lb Spring Weight
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
SRAM NX Eagle, 12 speed, Single Click
Cassette
SRAM NX Eagle, 11-50T
Crank
Shimano FC-E8000, 165mm, 34T SRAM Eagle narrow/wide
Bottom Bracket
Samox 104 BCD Spider, Shimano spline
Chain
SRAM NX Eagle
Chain Tensioner
e*thirteen Compact Upper Slider
Wheels
Front Hub
Novatec, sealed bearing 15x110mm Boost
Rear Hub
DT Swiss H370 E-MTB
Rims
e*thirteen LG1 DH, 27.5
Tires
Maxxis Assegai. 2.5” 3C Maxx Terra, EXO+,TR
Brakes
Brakes
SRAM Code R 4 piston, Hydraulic, 200mm
Cockpit
Stem
Norco 40mm, 35mm bore
Handlebar
Norco 6061 Aluminum, 800mm, 20mm rise, 35mm bore
Grips
Ergon GE10 EVO, lock on
Headset
Acros Block Lock, sealed bearing
Seat
Saddle
Ergon SM-10 E-Mountain Sport
Seatpost
JD TranzX YSP-39JL Dropper M 150mm, L/XL170mm, 1x lever
Motor & Battery
Motor
Shimano STEPS E8000
Battery
In-Tube Battery, 630Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.33 mm | 1.27 mm | 1.21 mm |
| Bottom Bracket Height | 355 mm | 355 mm | 355 mm |
| Front Center | 789 mm | 823 mm | 858 mm |
| Rake | 37 mm | 37 mm | 37 mm |
| Trail | 138 mm | 138 mm | 138 mm |
| Stack | 607 mm | 615 mm | 624 mm |
| Reach | 455 mm | 485 mm | 515 mm |
| Top Tube Length | 590 mm | 619 mm | 647 mm |
| Seat Tube Angle | 77.3 ° | 77.7 ° | 78 ° |
| Seat Tube Length | 405 mm | 445 mm | 485 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1234 mm | 1268 mm | 1303 mm |
| Bottom Bracket Drop | 5 mm | 5 mm | 5 mm |
| Standover Height | 712 mm | 726 mm | 739 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Range VLT C2 belongs to the Norco E Range model. 14 e-bikes variations carry this model name so far. Take a sneak peek at all Norco E Range e-bikes models from 2020, by clicking here.
Model range prices
The most economical model, the Norco Range VLT C3 2020 has a starting price of 5399$. Norco Range VLT C1 2020 on the other hand is the most expensive at 7499$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro e-bikes average price
If you want an acceptable Enduro e-bike you should know that the average price is 4785$. However, this doesn’t mean that if you spend less money on an Enduro e-bike, you couldn’t get a decent one. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Norco Range VLT C2 price was 6599$. Comparing the average cost of an Enduro e-bike to this one, you will see that Range VLT C2 price is 37.91% more expensive.
Range VLT C2 components
Fork
Norco Range VLT C2 2020 e-bike is equipped with the Fox Performance Elite Float 36 fork, and has 180mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
From the factory, it comes with the Fox Performance Elite DHX2 rear shock model, which has a travel of 170mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
When leaving the production line, the Range VLT C2 model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Range VLT C2 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 3 sizes. They vary from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Norco Range VLT C2 comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
