Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 27.5" -
Travel Front 100mm -
Travel Rear 100mm -
Fork RockShox SID
-
Groupset XX1 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Revolver XC High-Modulus Carbon 27.5 FS Frame
Suspension Fork
Rock Shox Sid World Cup 27.5" 100mm/15mm"
Rear Shock
Rock Shox Monarch RL 100mm
Drivetrain
Rear Derailleur
SRAM XX1 Eagle 12spd
Front Derailleur
N/A
Shift Levers
N/A
Cassette
SRAM XG1295 10/50 12spd
Crank
SRAM XX1 Eagle 34T 12spd
Bottom Bracket
SRAM PF BB92
Chain
SRAM PC-XX1 12spd Gold
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
DT Swiss XRC 1200 Spline Wheelset
Rear Hub
DT Swiss XRC 1200 Spline Wheelset
Rims
DT Swiss
Tires
Maxxis Ikon 27.5"x2.20 3C/TR/EXO"
Brakes
Brakes
SRAM Level Ultimate 180mm
Brake Levers
SRAM Level Ultimate
Disk Rotors
N/A
Cockpit
Stem
Race Face Turbine 35mm
Handlebar
Race Face Next SL Carbon 740mm/10mm
Grips
Norco Lock On Grip
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
SDG Duster RL
Seatpost
Race Face Next 30.9/400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.35 mm | 1.31 mm | 1.27 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm | 330 mm |
| Front Center | 628 mm | 651 mm | 673 mm | 696 mm | 718 mm |
| Rake | 42 mm | 42 mm | 43 mm | 42 mm | 41 mm |
| Trail | 85 mm | 83 mm | 80 mm | 80 mm | 79 mm |
| Stack | 555 mm | 565 mm | 576 mm | 586 mm | 597 mm |
| Reach | 384 mm | 406 mm | 427 mm | 449 mm | 471 mm |
| Top Tube Length | 534 mm | 561 mm | 588 mm | 615 mm | 642 mm |
| Seat Tube Angle | 75 ° | 74.75 ° | 74.5 ° | 74.25 ° | 74 ° |
| Seat Tube Length | 380 mm | 410 mm | 445 mm | 485 mm | 530 mm |
| Head Tube Angle | 70 ° | 70.25 ° | 70.5 ° | 70.75 ° | 71 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 419 mm | 421 mm | 424 mm | 428 mm | 432 mm |
| Wheelbase | 1046 mm | 1071 mm | 1097 mm | 1123 mm | 1149 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 736 mm | 748 mm | 742 mm | 736 mm | 727 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| Rear Travel | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Revolver 7XX1 FS is part of the Norco Revolver model. Norco released 148 bikes variations of this model so far. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
Norco Revolver 9.3 HT 2017 is the cheapest bike model and costs 2099$. Norco Revolver 7XX1 FS 2017 is the most expensive one and costs 7299$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Norco released this model in 2017, its price was 7299$. Comparing the average cost of a Crosscountry bike to this one, you will see that Revolver 7XX1 FS price is 283.15% more expensive.
Revolver 7XX1 FS components
Fork
The fork installed on this bike is the RockShox SID model. The travel on this model is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The shock that’s installed on this bike is Rock Shox Monarch RL 100mm, with a travel distance of 100mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When it comes to wheels, the Revolver 7XX1 FS bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Revolver 7XX1 FS comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
