Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 27.5" -
Travel Front 100mm -
Fork RockShox Reba
-
Groupset SLX, Deore -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco XC Mid-Mod Carbon 29
Suspension Fork
Rock Shox Reba RL 29100mm/15mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano SLX 10spd Shadow
Front Derailleur
Shimano Deore 2spd
Shift Levers
Jagwire
Cassette
Shimano HG5010 11-36
Crank
FSA V-Drive PF30 36/22
Bottom Bracket
FSA PF30
Chain
KMC X10
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
Norco Alloy 15mm
Rear Hub
Norco Alloy 142x12
Rims
DT Swiss 444d 29
Tires
WTB Nineline 29 x 2.0
Brakes
Brakes
Shimano Deore 615 Hydraulic 160mm
Brake Levers
Shimano Deore 615
Disk Rotors
N/A
Cockpit
Stem
Norco Alloy
Handlebar
Norco Lite 720mm Flat Bar
Grips
Norco SL Silicon
Headset
FSA No.42 Tapered
Seat
Saddle
SDG Circuit MTN Steel Rail
Seatpost
Norco Alloy 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.47 mm | 1.44 mm | 1.41 mm |
| Bottom Bracket Height | 303 mm | 303 mm | 303 mm | 303 mm |
| Front Center | 638.1 mm | 659.4 mm | 681.4 mm | 704.1 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 79 mm | 77 mm | 75 mm | 74 mm |
| Stack | 616.1 mm | 617.2 mm | 632.4 mm | 647.7 mm |
| Reach | 394.9 mm | 418.7 mm | 438.2 mm | 458.5 mm |
| Top Tube Length | 573 mm | 600 mm | 627 mm | 655 mm |
| Seat Tube Angle | 73.75 ° | 73.5 ° | 73.25 ° | 73 ° |
| Seat Tube Length | 405 mm | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 70.25 ° | 70.5 ° | 70.75 ° | 71 ° |
| Head Tube Length | 90 mm | 90 mm | 105 mm | 120 mm |
| Chainstay Length | 440 mm | 442 mm | 445 mm | 447 mm |
| Wheelbase | 1069 mm | 1093 mm | 1118 mm | 1143 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 750 mm | 790 mm | 817 mm | 846 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Revolver 9.2 is part of the Norco Revolver model. There are 148 bikes that carry this model name. You can easily view all of the Norco Revolver bikes models from 2015, here.
Model range prices
Norco Revolver 7.3 2015 is the most affordable bike of this model and has a price of 1880$. On the other hand, Norco Revolver 9 SL XX1 2015, is the most expensive and costs 8775$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2015 for 2495$. Comparing this to the average Crosscountry bike price, we see that the price is 30.97% higher.
Overview of components
Fork
The fork installed on this bike is the RockShox Reba model. The travel on this model is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Norco Revolver 9.2 2015, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Revolver 9.2 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
