Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Groupset Deore, FSA -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco XC Mid-Mod Carbon 29
Suspension Fork
Rock Shox XC32 29 Solo Air 100mm/15mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Deore Shadow 10spd
Front Derailleur
Shimano Deore
Shift Levers
Jagwire
Cassette
Shimano HG5010 11/36
Crank
FSA Comet PF30 36/22
Bottom Bracket
FSA PF30
Chain
KMC X10
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
Norco Alloy 15mm
Rear Hub
Norco Alloy 142x12
Rims
WTB SX19 29
Tires
WTB Nineline 29 x 2.0
Brakes
Brakes
Tektro Auriga HD-290 160mm
Brake Levers
Tektro Auriga HD-290
Disk Rotors
N/A
Cockpit
Stem
Norco Alloy
Handlebar
Norco Lite 720mm Flat Bar
Grips
Norco SL Silicon
Headset
FSA No.42 Tapered
Seat
Saddle
SDG Circuit MTN Steel Rail
Seatpost
Norco Alloy 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.47 mm | 1.44 mm | 1.41 mm |
| Bottom Bracket Height | 303 mm | 303 mm | 303 mm | 303 mm |
| Front Center | 638.1 mm | 659.4 mm | 681.4 mm | 704.1 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 86 mm | 84 mm | 82 mm | 80 mm |
| Stack | 616.1 mm | 617.2 mm | 632.4 mm | 647.7 mm |
| Reach | 394.9 mm | 418.7 mm | 438.2 mm | 458.5 mm |
| Top Tube Length | 573 mm | 600 mm | 627 mm | 655 mm |
| Seat Tube Angle | 73.75 ° | 73.5 ° | 73.25 ° | 73 ° |
| Seat Tube Length | 405 mm | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 70.25 ° | 70.5 ° | 70.75 ° | 71 ° |
| Head Tube Length | 90 mm | 90 mm | 105 mm | 120 mm |
| Chainstay Length | 440 mm | 442 mm | 445 mm | 447 mm |
| Wheelbase | 1069 mm | 1093 mm | 1118 mm | 1143 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 750 mm | 790 mm | 817 mm | 846 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Revolver 9.3 belongs to the Norco Revolver model. There are 148 bikes that carry this model name. You can get a glimpse at all models from 2015, by clicking on this link.
Model range prices
Norco Revolver 7.3 2015 is the cheapest bike model and costs 1880$. Norco Revolver 9 SL XX1 2015 is the most expensive one and costs 8775$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2015 and its price was 1915$. Doing a quick comparison, we notice that Revolver 9.3 price is 0.52% higher than the average cost of a Crosscountry bike.
Overview of components
Wheels size
When leaving the production line, the Revolver 9.3 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Norco Revolver 9.3 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
