Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Recon Silver RL
-
Groupset GX, SRAM -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco XC MId-Modulus Carbon
Suspension Fork
Rock Shox Recon Silver 29" Solo Air 100mm/15mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM GX 11spd
Front Derailleur
N/A
Shift Levers
Jagwire
Cassette
SRAM XG 1150 11spd 10/42
Crank
SRAM S1000 32T
Bottom Bracket
SRAM PF30
Chain
SRAM PC-1130 11spd
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
Norco Alloy 15mm
Rear Hub
Norco Alloy 142x12
Rims
Alex DP21 TR 29Ó
Tires
N/A
Brakes
Brakes
Shimano M355 Hydraulic 160mm
Brake Levers
Shimano Deore BL-M355
Disk Rotors
N/A
Cockpit
Stem
Norco Alloy
Handlebar
Norco Lite 720mm Flat Bar
Grips
Norco SL Silicon
Headset
Tapered
Seat
Saddle
SDG Circuit MTN Steel Rail
Seatpost
Norco Alloy 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.47 mm | 1.44 mm | 1.41 mm |
| Bottom Bracket Height | 303 mm | 303 mm | 303 mm | 303 mm |
| Front Center | 638.1 mm | 659.4 mm | 681.4 mm | 704.1 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 86 mm | 84 mm | 82 mm | 80 mm |
| Stack | 616.1 mm | 617.2 mm | 632.4 mm | 647.7 mm |
| Reach | 394.9 mm | 418.7 mm | 438.2 mm | 458.5 mm |
| Top Tube Length | 573 mm | 600 mm | 627 mm | 655 mm |
| Seat Tube Angle | 73.75 ° | 73.5 ° | 73.25 ° | 73 ° |
| Seat Tube Length | 405 mm | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 70.25 ° | 70.5 ° | 70.75 ° | 71 ° |
| Head Tube Length | 90 mm | 90 mm | 105 mm | 120 mm |
| Chainstay Length | 440 mm | 442 mm | 445 mm | 447 mm |
| Wheelbase | 1069 mm | 1093 mm | 1118 mm | 1143 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 750 mm | 790 mm | 817 mm | 846 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Revolver 9.3 completes the Norco Revolver model. 148 bikes variations carry this model name so far. Take a sneak peek at all Norco Revolver bikes models from 2016, by clicking here.
Model range prices
Norco Revolver 9.3 2016 is the most affordable bike of this model and has a price of 2075$. On the other hand, Norco Revolver 7XX 2016, is the most expensive and costs 7415$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2016 and its price was 2075$. In conclusion, this bike price is 8.92% more expensive than the price of the average Crosscountry bike.
Revolver 9.3 components
Fork
Norco Revolver 9.3 2016 bike is equipped with the RockShox Recon Silver RL fork, and has 100mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Norco Revolver 9.3 2016, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Revolver 9.3 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Norco Revolver 9.3 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
