Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox SID Select
-
Groupset NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hi-Mod Carbon, 120mm Rear Travel
Suspension Fork
Rock Shox Sid Select, 120mm Travel, Boost
Rear Shock
Rockshox Deluxe Select+ RL
Drivetrain
Rear Derailleur
SRAM NX Eagle, 12 speed
Shift Levers
SRAM NX Eagle 12 speed, MMX
Cassette
SRAM PG1230 Eagle, 11-50T
Crank
SRAM NX Eagle DUB 32T
Bottom Bracket
SRAM DUB, Press Fit, 92mm
Chain
SRAM NX Eagle, 12 speed
Wheels
Front Hub
Novatec Boost, 110mm x 15mm, 28H
Rear Hub
DT Swiss 370, 148mm x 12mm
Rims
Stans Arch D, 29" 32H
Tires
Maxxis Forekaster, 29 x 2.35"
Brakes
Brakes
SRAM Guide T, 180mm
Cockpit
Stem
SL Aluminum, 60mm Length
Handlebar
6061 DB Aluminum, 31.8mm, 760mm Length, 15mm Rise
Grips
Ergon GA30, Lock-on
Headset
FSA Internal
Seat
Saddle
Fizik Taiga
Seatpost
Crank Bros. Highline 3, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.32 mm | 1.25 mm | 1.2 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 699 mm | 729 mm | 763 mm | 797 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 100 mm | 100 mm | 100 mm | 100 mm |
| Stack | 578 mm | 579 mm | 588 mm | 598 mm |
| Reach | 409 mm | 439 mm | 469 mm | 500 mm |
| Top Tube Length | 568 mm | 598 mm | 631 mm | 663 mm |
| Seat Tube Angle | 74.9 ° | 74.9 ° | 74.9 ° | 74.9 ° |
| Seat Tube Length | 425 mm | 440 mm | 485 mm | 510 mm |
| Head Tube Angle | 67.4 ° | 67.4 ° | 67.4 ° | 67.4 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 411 mm | 414 mm | 417 mm | 421 mm |
| Wheelbase | 1108 mm | 1141 mm | 1179 mm | 1216 mm |
| Bottom Bracket Drop | 32 mm | 32 mm | 32 mm | 32 mm |
| Standover Height | 700 | 707 mm | 708 mm | 717 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Revolver FS 2 120 is part of the Norco Revolver model. Norco released 148 bikes variations of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
Norco Revolver HT 2 120 2020 is the most affordable bike of this model and has a price of 2599$. On the other hand, Norco Revolver FS AXS 120 2020, is the most expensive and costs 8699$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3999$. Comparing the average cost of a Trail bike to this one, you will see that Revolver FS 2 120 price is 44.79% more expensive.
Revolver FS 2 120 components
Fork
Norco Revolver FS 2 120 2020 bike is equipped with the RockShox SID Select fork, and has 120mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Norco Revolver FS 2 120 bike has the Rockshox Deluxe Select+ RL model installed, and has a travel of 120mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The Revolver FS 2 120 2020 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Revolver FS 2 120 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Norco Revolver FS 2 120 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the Revolver FS 2 120. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
