Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 27.5" / 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork RockShox SID
-
Groupset GX Eagle, Truvativ Stylo -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Revolver FS Hi-Mod Carbon 100mm XC Race Frame
Suspension Fork
Rock Shox Sid RL 100mm - 110mm/15mm
Rear Shock
Rockshox Monarch RL
Drivetrain
Rear Derailleur
SRAM GX Eagle 12spd
Front Derailleur
N/A
Shift Levers
SRAM GX Eagle 12spd
Cassette
SRAM XG 1275 12spd 10/50
Crank
Truvativ Stylo 6K Eagle 34T DM
Bottom Bracket
SRAM PF MTB
Chain
SRAM GX Eagle 12spd
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
DT Swiss M1900 Spline Wheelset 25mm
Rear Hub
DT Swiss M1900 Spline Wheelset 25mm
Rims
DT Swiss M1900 Spline Wheelset 25mm
Spokes
DT Swiss
Tires
Maxxis Ikon 29"x 2.2"/27.5" x 2.2" TR/EXO
Brakes
Brakes
SRAM Level TL 180mm
Brake Levers
SRAM Level TL
Cockpit
Stem
Norco SL Alloy Stem
Handlebar
Norco DB Lite 760mm 15mm Riser
Grips
Ergon GA30 Lock On Grip
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
SDG Duster RL
Seatpost
Norco SL Alloy Post 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.41 mm | 1.33 mm | 1.29 mm | 1.25 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm | 330 mm |
| Front Center | 628 mm | 666 mm | 687 mm | 710 mm | 732 mm |
| Rake | 42 mm | 51 mm | 52 mm | 50 mm | 52 mm |
| Trail | 85 mm | 80 mm | 77 mm | 78 mm | 74 mm |
| Stack | 555 mm | 579 mm | 580 mm | 591 mm | 601 mm |
| Reach | 384 mm | 412 mm | 436 mm | 458 mm | 479 mm |
| Top Tube Length | 534 mm | 571 mm | 598 mm | 625 mm | 652 mm |
| Seat Tube Angle | 75 ° | 74.75 ° | 74.5 ° | 74.25 ° | 74 ° |
| Seat Tube Length | 380 mm | 410 mm | 445 mm | 485 mm | 530 mm |
| Head Tube Angle | 70 ° | 70.25 ° | 70.5 ° | 70.75 ° | 71 ° |
| Head Tube Length | 100 mm | 90 mm | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 419 mm | 434 mm | 436 mm | 439 mm | 441 mm |
| Wheelbase | 1046 mm | 1097 mm | 1121 mm | 1146 mm | 1171 mm |
| Bottom Bracket Drop | 20 mm | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 736 mm | 772 mm | 762 mm | 757 mm | 749 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| Rear Travel | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 27" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Revolver FS 2 is part of the Norco Revolver model. 148 bikes variations carry this model name so far. You can get a glimpse at all models from 2018, by clicking on this link.
Model range prices
Norco Revolver HT 3 2018 is the cheapest bike model and costs 2199$. Norco Revolver FS XX1 2018 is the most expensive one and costs 7699$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4099$. Doing a quick comparison, we notice that Revolver FS 2 price is 115.17% more expensive than the average cost of a Crosscountry bike.
Revolver FS 2 components
Fork
The Revolver FS 2 comes factory-installed with the RockShox SID fork. This has a travel range of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Norco Revolver FS 2 bike has the Rockshox Monarch RL model installed, and has a travel of 100mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
When leaving the production line, the Revolver FS 2 model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Revolver FS 2 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Revolver FS 2 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
