Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 27.5" -
Travel Front 100mm -
Travel Rear 100mm -
Fork RockShox Judy Gold RL
-
Groupset NX, Race Face -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
RockShox Judy Gold RL Solo Air, 15mm thru axle
Rear Shock
RockShox Monarch RL
Drivetrain
Rear Derailleur
SRAM NX, 11-speed
Front Derailleur
N/A
Shift Levers
SRAM NX, 11-speed
Cassette
SRAM NX PG 1130, 11-42 tooth, 11-speed
Crank
Race Face Aeffect, direct mount
Bottom Bracket
Race Face BB92
Chain
SRAM PC-1110, 11-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
Front: Novatec D041SB-B15 110mm x 15mm, Rear: Novatec D162SB-SL-X12 142mm x 12mm
Rear Hub
Front: Novatec D041SB-B15 110mm x 15mm, Rear: Novatec D162SB-SL-X12 142mm x 12mm
Rims
Alex DP-23 TRS
Spokes
Stainless steel 14g, black
Tires
Maxxis Ikon 2.2", TR, EXO
Brakes
Brakes
Tektro HD-M285, 2 piston hydraulic disc, 160mm rotors
Brake Levers
Tektro HD-M285
Cockpit
Stem
Norco SL alloy
Handlebar
Norco DB Lite, 760mm, 15mm rise
Grips
Ergon GA30, Lock-on
Headset
Angular sealed cartridge bearings
Seat
Saddle
SDG Duster RL
Seatpost
Norco SL alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.41 mm | 1.33 mm | 1.29 mm | 1.25 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm | 330 mm |
| Stack | 555 mm | 579 mm | 580 mm | 591 mm | 601 mm |
| Reach | 384 mm | 412 mm | 436 mm | 458 mm | 479 mm |
| Top Tube Length | 534 mm | 571 mm | 598 mm | 625 mm | 652 mm |
| Seat Tube Angle | 75 ° | 74.75 ° | 74.5 ° | 74.25 ° | 74 ° |
| Seat Tube Length | 380 mm | 410 mm | 445 mm | 485 mm | 530 mm |
| Head Tube Angle | 70 ° | 70.25 ° | 70.5 ° | 70.75 ° | 71 ° |
| Head Tube Length | 100 mm | 90 mm | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 419 mm | 434 mm | 436 mm | 439 mm | 441 mm |
| Wheelbase | 1046 mm | 1097 mm | 1121 mm | 1146 mm | 1171 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 736 mm | 772 mm | 762 mm | 757 mm | 749 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Revolver FS 3 belongs to the Norco Revolver model. 148 bikes variations carry this model name so far. Take a sneak peek at all Norco Revolver bikes models from 2019, by clicking here.
Model range prices
The most economical model, the Norco Revolver HT 3 2019 has a starting price of 2199$. Norco Revolver HT XX1 29 2019 on the other hand is the most expensive at 6899$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Norco Revolver FS 3 price was 2499$. Comparing this to the average Crosscountry bike price, we see that the price is 31.18% more expensive.
Overview of components
Fork
The fork installed on this bike is the RockShox Judy Gold RL model. The travel on this model is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Norco Revolver FS 3 bike has the RockShox Monarch RL model installed, and has a travel of 100mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When leaving the production line, the Revolver FS 3 model has 27.5″ aluminum wheels. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Revolver FS 3 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Norco Revolver FS 3 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
