Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork RockShox Judy Gold RL
-
Groupset NX, Race Face -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Revolver FS Hi-Mod Carbon 100mm XC Race Frame
Suspension Fork
Rock Shox Judy Gold RL Solo Air 100mm - 110mm/15mm
Rear Shock
Rockshox Monarch RL
Drivetrain
Rear Derailleur
SRAM NX 11spd
Shift Levers
SRAM NX 11spd
Cassette
SRAM NX PG 1130 11/42
Crank
Race Face Aeffect 32T DM
Bottom Bracket
Race Face BB92
Chain
SRAM PC-1110 11spd
Wheels
Front Hub
Novatec D041SB-B15 110mm x 15mm
Rear Hub
Novatec D162SB-SL-X12 142mm x 12mm
Rims
Alex DP-23 29"/27.5" TRS
Tires
Maxxis Ikon 29"x 2.2"/27.5" x 2.2"
Brakes
Brakes
Tektro HD-M285 Hydraulic 160mm
Brake Levers
Tektro HD-M285
Cockpit
Stem
Norco SL Alloy Stem
Handlebar
Norco DB Lite 760mm 15mm Riser
Grips
Ergon GA30 Lock On Grip
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
SDG Duster RL
Seatpost
Norco SL Alloy Post 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.33 mm | 1.29 mm | 1.26 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm |
| Front Center | 666 mm | 687 mm | 710 mm | 732 mm |
| Rake | 51 mm | 52 mm | 50 mm | 52 mm |
| Trail | 80 mm | 77 mm | 78 mm | 74 mm |
| Stack | 575 mm | 576 mm | 587 mm | 597 mm |
| Reach | 408 mm | 432 mm | 454 mm | 475 mm |
| Top Tube Length | 567 mm | 594 mm | 621 mm | 648 mm |
| Seat Tube Angle | 74.75 ° | 74.5 ° | 74.25 ° | 74 ° |
| Seat Tube Length | 410 mm | 445 mm | 485 mm | 530 mm |
| Head Tube Angle | 70.25 ° | 70.5 ° | 70.75 ° | 71 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 430 mm | 432 mm | 435 mm | 437 mm |
| Wheelbase | 1093 mm | 1117 mm | 1142 mm | 1167 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 768 mm | 758 mm | 753 mm | 745 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Revolver FS 3 29 belongs to the Norco Revolver model. Norco launched 148 bikes of this model so far. Take a sneak peek at all Norco Revolver bikes models from 2019, by clicking here.
Model range prices
Norco Revolver HT 3 2019 is the cheapest bike model and costs 2199$. Norco Revolver HT XX1 29 2019 is the most expensive one and costs 6899$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2019 for 2499$. Comparing this to the average Crosscountry bike price, we see that the price is 31.18% higher.
Overview of components
Fork
Norco Revolver FS 3 29 2019 bike is equipped with the RockShox Judy Gold RL fork, and has 100mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The shock that’s installed on this bike is Rockshox Monarch RL, with a travel distance of 100mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When it comes to wheels, the Revolver FS 3 29 bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Revolver FS 3 29 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Norco Revolver FS 3 29 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
