Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Fork RockShox SID Select
-
Groupset GX Eagle, X1 -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon XC Race
Suspension Fork
RockShox SID Select, 120mm Travel
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM GX Eagle 12spd
Cassette
SRAM XG 1275 10-50T
Crank
SRAM X1 Eagle DUB Carbon 32T
Bottom Bracket
SRAM BB DUB PressFit
Chain
SRAM NX Eagle
Wheels
Front Hub
DT Swiss 350, 15x110
Rear Hub
DT Swiss 350, 12x148mm Boost
Rims
Stans Arch S1 29"
Tires
Schwalbe Nobby Nic 29"x2.35" Snakeskin TL/Addix Spd Grip
Brakes
Brakes
Shimano BR-MT501, 180mm
Cockpit
Stem
Norco SL Alloy
Handlebar
Norco DB Lite, 760mm, 15mm rise
Grips
Ergon GA30 lock on
Headset
FSA Internal Headset
Seat
Saddle
Fizik Taiga
Seatpost
X-Fusion Manic 125mm dropper, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.35 mm | 1.28 mm | 1.22 mm |
| Bottom Bracket Height | 321 mm | 321 mm | 321 mm | 321 mm |
| Front Center | 706 mm | 736 mm | 770 mm | 803 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 97 mm | 97 mm | 97 mm | 97 mm |
| Stack | 596 mm | 596 mm | 605 mm | 615 mm |
| Reach | 413 mm | 443 mm | 473 mm | 503 mm |
| Top Tube Length | 572 mm | 602 mm | 635 mm | 667 mm |
| Seat Tube Angle | 75.3 ° | 75.3 ° | 75.3 ° | 75.3 ° |
| Seat Tube Length | 425 mm | 440 mm | 485 mm | 510 mm |
| Head Tube Angle | 67.8 ° | 67.8 ° | 67.8 ° | 67.8 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 411 mm | 414 mm | 417 mm | 421 mm |
| Wheelbase | 1111 mm | 1145 mm | 1182 mm | 1219 mm |
| Bottom Bracket Drop | 54 mm | 54 mm | 54 mm | 54 mm |
| Standover Height | 666 mm | 683 mm | 718 mm | 741 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Revolver HT 1 120 completes the Norco Revolver model. 148 bikes variations carry this model name so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
Norco Revolver HT 2 120 2020 is the most affordable bike of this model and has a price of 2599$. On the other hand, Norco Revolver FS AXS 120 2020, is the most expensive and costs 8699$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Norco released this model in 2020, its price was 3599$. If we compare this with the average Trail bike cost we notice that the price is 30.3% higher.
Revolver HT 1 120 components
Fork
This bike has the RockShox SID Select fork installed. The fork’s travel is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
As for the wheels, Norco Revolver HT 1 120 2020, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Revolver HT 1 120 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Norco Revolver HT 1 120 comes with a dropper post. Therefore, climbing or descending will be a breeze.
