Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 27.5" / 29" -
Travel Front 100mm -
Fork RockShox SID
-
Groupset GX Eagle, Truvativ Stylo -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Revolver HT Carbon XC Race Frame
Suspension Fork
Rock Shox Sid RL 100mm - 110mm/15mm
Drivetrain
Rear Derailleur
SRAM GX Eagle 12spd
Shift Levers
SRAM GX Eagle 12spd
Cassette
SRAM XG 1275 12spd 10/50
Crank
Truvativ Stylo 6K Eagle 34T DM
Bottom Bracket
SRAM PF MTB
Chain
SRAM GX Eagle 12spd
Wheels
Front Hub
DT Swiss M1900 Spline Wheelset 25mm
Rear Hub
DT Swiss M1900 Spline Wheelset 25mm
Rims
DT Swiss M1900 Spline Wheelset 25mm
Tires
Maxxis Ikon 29"x 2.2"/27.5" x 2.2" TR/EXO
Brakes
Brakes
SRAM Level TL 180mm
Brake Levers
SRAM Level TL
Cockpit
Stem
Norco SL Alloy Stem
Handlebar
Norco DB Lite 760mm 15mm Riser
Grips
Ergon GA30 Lock On Grip
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
SDG Duster RL
Seatpost
Norco SL Alloy Post 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.56 mm | 1.48 mm | 1.45 mm | 1.42 mm |
| Bottom Bracket Height | 305 mm | 303 mm | 303 mm | 303 mm | 303 mm |
| Front Center | 621 mm | 638.1 mm | 659.4 mm | 681.4 mm | 704.1 mm |
| Rake | 41 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 89 mm | 86 mm | 84 mm | 82 mm | 80 mm |
| Stack | 585 mm | 613.1 mm | 614.2 mm | 629.4 mm | 644.7 mm |
| Reach | 376 mm | 391.9 mm | 415.7 mm | 435.2 mm | 455.5 mm |
| Top Tube Length | 543 mm | 570 mm | 597 mm | 624 mm | 652 mm |
| Seat Tube Angle | 74 ° | 73.75 ° | 73.5 ° | 73.25 ° | 73 ° |
| Seat Tube Length | 368 mm | 405 mm | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 69.5 ° | 70.25 ° | 70.5 ° | 70.75 ° | 71 ° |
| Head Tube Length | 100 mm | 90 mm | 90 mm | 105 mm | 120 mm |
| Chainstay Length | 424 mm | 437 mm | 439 mm | 442 mm | 444 mm |
| Wheelbase | 1040 mm | 1066 mm | 1090 mm | 1115 mm | 1140 mm |
| Bottom Bracket Drop | 47 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 727 mm | 747 mm | 787 mm | 814 mm | 843 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 27" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Revolver HT 2 belongs to the Norco Revolver model. Norco launched 148 bikes of this model so far. You can get a glimpse at all models from 2018, by clicking on this link.
Model range prices
Norco Revolver HT 3 2018 is the most affordable bike of this model and has a price of 2199$. On the other hand, Norco Revolver FS XX1 2018, is the most expensive and costs 7699$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2018 and its price was 3099$. If we compare this with the average Crosscountry bike cost we notice that the price is 62.68% higher.
Overview of components
Fork
This bike has the RockShox SID fork installed. The fork’s travel is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When leaving the production line, the Revolver HT 2 model has 27.5″ aluminum wheels. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Revolver HT 2 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Norco Revolver HT 2 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
