Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 27.5" -
Travel Front 100mm -
Fork RockShox SID
-
Groupset GX Eagle, Truvativ Stylo -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
RockShox Sid RL, 15mm thru axle
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM GX Eagle,12-speed
Front Derailleur
N/A
Shift Levers
SRAM GX Eagle,12-speed
Cassette
SRAM XG 1275 Eagle, 10-50 tooth, 12-speed
Crank
Truvativ Stylo 6K Eagle, direct mount
Bottom Bracket
SRAM pressfit MTB
Chain
SRAM GX Eagle, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
DT Swiss M1900 Spline wheelset
Rear Hub
DT Swiss M1900 Spline wheelset
Rims
DT Swiss M1900 Spline wheelset, 25mm
Spokes
DT Swiss Champion, straight pull
Tires
Maxxis Ikon 2.2", TR, EXO
Brakes
Brakes
Front: SRAM Level TL, 180mm rotor, Rear: SRAM Level TL, 160mm rotor
Brake Levers
SRAM Level TL
Cockpit
Stem
Norco SL alloy
Handlebar
Norco DB Lite, 760mm, 15mm rise
Grips
Ergon GA30, Lock-on
Headset
Angular sealed cartridge bearings
Seat
Saddle
SDG Duster RL
Seatpost
Norco SL alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.56 mm | 1.48 mm | 1.45 mm | 1.42 mm |
| Bottom Bracket Height | 305 mm | 303 mm | 303 mm | 303 mm | 303 mm |
| Stack | 585 mm | 613.1 mm | 614.2 mm | 629.4 mm | 644.7 mm |
| Reach | 376 mm | 391.9 mm | 415.7 mm | 435.2 mm | 455.5 mm |
| Top Tube Length | 543 mm | 570 mm | 597 mm | 624 mm | 652 mm |
| Seat Tube Angle | 74 ° | 73.75 ° | 73.5 ° | 73.25 ° | 73 ° |
| Seat Tube Length | 368 mm | 405 mm | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 69.5 ° | 70.25 ° | 70.5 ° | 70.75 ° | 71 ° |
| Head Tube Length | 100 mm | 90 mm | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 424 mm | 437 mm | 439 mm | 442 mm | 444 mm |
| Wheelbase | 1040 mm | 1066 mm | 1090 mm | 1115 mm | 1140 mm |
| Bottom Bracket Drop | 50 mm | 52 mm | 52 mm | 52 mm | 52 mm |
| Standover Height | 727 mm | 747 mm | 787 mm | 814 mm | 843 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Revolver HT 2 belongs to the Norco Revolver model. 148 bikes variations carry this model name so far. Take a sneak peek at all Norco Revolver bikes models from 2019, by clicking here.
Model range prices
Norco Revolver HT 3 2019 is the most affordable bike of this model and has a price of 2199$. On the other hand, Norco Revolver HT XX1 29 2019, is the most expensive and costs 6899$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3099$. If we compare this with the average Crosscountry bike cost we notice that the price is 62.68% higher.
Overview of components
Fork
This bike has the RockShox SID fork installed. The fork’s travel is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When it comes to wheels, the Revolver HT 2 bike is equipped with the 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Revolver HT 2 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Revolver HT 2 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
