Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Fork X-Fusion RC32
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 166cm
MD
163cm - 175cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon XC Race, Ride Aligned™
Suspension Fork
X-Fusion RC32 Boost Air, 120mm, 51mm Offset
Drivetrain
Rear Derailleur
Shimano Deore RD-M5100
Shift Levers
Shimano Deore SL-M5100
Cassette
Shimano Deore CS-M5100, 11-51T, 11 Speed
Crank
Shimano Deore FC-M5100-1, 32T, 170mm (S), 175mm (M, L, XL)
Bottom Bracket
Shimano BBMT500PA PF92
Chain
KMC X11
Wheels
Front Hub
Sealed Bearing, 15x110mm Boost, 6 Bolt
Rear Hub
Alloy RR, 12x148mm Boost, HG, 6 Bolt
Rims
Stans Arch D 29" 32H
Tires
Front: Schwalbe Nobby Nic Performance 2.35", Folding Addix, Rear: Schwalbe Nobby Nic Performance 2.35", Folding Addix
Brakes
Brakes
Front: Shimano BRMT400, Resin Pads, Rear: Shimano BRMT400, Resin Pads
Brake Levers
Shimano BRMT400
Cockpit
Stem
Norco SL Alloy Stem, 60mm Length, 31.8mm Clamp
Handlebar
Butted Alloy Lite, 760mm, 15mm Rise
Grips
VP Lock-On
Headset
Angular Cartridge Bearing
Seat
Saddle
Fizik Alpaca Terra, Wingflex
Seatpost
TranzX YSP18 Dropper, 31.6mm, 130mm (S, M), 150mm (L, XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.35 mm | 1.28 mm | 1.22 mm |
| Bottom Bracket Height | 321 mm | 321 mm | 321 mm | 321 mm |
| Front Center | 706 mm | 736 mm | 770 mm | 803 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 97 mm | 97 mm | 97 mm | 97 mm |
| Stack | 596 mm | 596 mm | 605 mm | 615 mm |
| Reach | 413 mm | 443 mm | 473 mm | 503 mm |
| Top Tube Length | 572 mm | 602 mm | 635 mm | 667 mm |
| Seat Tube Angle | 75.3 ° | 75.3 ° | 75.3 ° | 75.3 ° |
| Seat Tube Length | 425 mm | 440 mm | 485 mm | 510 mm |
| Head Tube Angle | 67.8 ° | 67.8 ° | 67.8 ° | 67.8 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 411 mm | 414 mm | 417 mm | 421 mm |
| Wheelbase | 1111 mm | 1145 mm | 1182 mm | 1219 mm |
| Bottom Bracket Drop | 54 mm | 54 mm | 54 mm | 54 mm |
| Standover Height | 666 mm | 683 mm | 718 mm | 741 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 163 cm | 172 cm | 181 cm |
| Rider Max Height | 166 cm | 175 cm | 184 cm | 191 cm |
Model Overview
Revolver HT 3 120 completes the Norco Revolver model. Norco launched 148 bikes of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Norco Revolver HT 3 120 2023 is the most economical model, with a starting price of 2799$. Norco Revolver FS 1 120 2023 on the other hand costs 6299$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2799$. Comparing this to the average Trail bike price, we see that the price is 1.34% more expensive.
Revolver HT 3 120 components
Fork
The Revolver HT 3 120 comes factory-installed with the X-Fusion RC32 fork. This has a travel range of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
As for the wheels, Norco Revolver HT 3 120 2023, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Revolver HT 3 120 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 154 cm – 191 cm (5.05 ft – 6.27 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
A dropper post is included with the Revolver HT 3 120. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
