Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 27.5" / 29" -
Travel Front 100mm -
Fork RockShox SID
-
Groupset XX1 Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Revolver SL HT Carbon XC Race Frame
Suspension Fork
RockShox Sid World Cup R 100mm - 110mm/15mm
Drivetrain
Rear Derailleur
SRAM XX1 Eagle 12spd
Shift Levers
SRAM XX1 Eagle 12spd
Cassette
SRAM XG1295 Eagle 10/50 12spd
Crank
SRAM XX1 Eagle 34T 12spd
Bottom Bracket
SRAM PF30 MTB
Chain
SRAM X01 Eagle 12spd Black
Wheels
Front Hub
DT Swiss XRC 1200 Spline Wheelset 25mm
Rear Hub
DT Swiss XRC 1200 Spline Wheelset 25mm
Rims
DT Swiss
Tires
Maxxis Ikon 29"x 2.2"/27.5" x 2.2" 3C/TR/EXO
Brakes
Brakes
SRAM Level Ultimate 180mm
Brake Levers
SRAM Level Ultimate
Cockpit
Stem
Race Face Turbine 35mm
Handlebar
Race Face Next SL Carbon 760mm/10mm
Grips
Ergon GA30 Lock On Grip
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
SDG Duster RL
Seatpost
Race Face Next 30.9/400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.56 mm | 1.48 mm | 1.45 mm | 1.42 mm |
| Bottom Bracket Height | 305 mm | 303 mm | 303 mm | 303 mm | 303 mm |
| Front Center | 621 mm | 638.1 mm | 659.4 mm | 681.4 mm | 704.1 mm |
| Rake | 41 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 89 mm | 86 mm | 84 mm | 82 mm | 80 mm |
| Stack | 585 mm | 613.1 mm | 614.2 mm | 629.4 mm | 644.7 mm |
| Reach | 376 mm | 391.9 mm | 415.7 mm | 435.2 mm | 455.5 mm |
| Top Tube Length | 543 mm | 570 mm | 597 mm | 624 mm | 652 mm |
| Seat Tube Angle | 74 ° | 73.75 ° | 73.5 ° | 73.25 ° | 73 ° |
| Seat Tube Length | 368 mm | 405 mm | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 69.5 ° | 70.25 ° | 70.5 ° | 70.75 ° | 71 ° |
| Head Tube Length | 100 mm | 90 mm | 90 mm | 105 mm | 120 mm |
| Chainstay Length | 424 mm | 437 mm | 439 mm | 442 mm | 444 mm |
| Wheelbase | 1040 mm | 1066 mm | 1090 mm | 1115 mm | 1140 mm |
| Bottom Bracket Drop | 47 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 727 mm | 747 mm | 787 mm | 814 mm | 843 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 27" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Revolver HT XX1 is part of the Norco Revolver model. Norco launched 148 bikes of this model so far. You can easily view all of the Norco Revolver bikes models from 2018, here.
Model range prices
Norco Revolver HT 3 2018 is the most economical model, with a starting price of 2199$. Norco Revolver FS XX1 2018 on the other hand costs 7699$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2018 for 6899$. If we compare this with the average Crosscountry bike cost we notice that the price is 262.15% more expensive.
Overview of components
Fork
The fork installed on this bike is the RockShox SID model. The travel on this model is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
As for the wheels, Norco Revolver HT XX1 2018, has a 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Revolver HT XX1 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
