Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 27.5" -
Travel Front 100mm -
Fork RockShox SID
-
Groupset XX1 Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
RockShox Sid World Cup R, 15mm thru axle
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM XX1 Eagle,12-speed
Front Derailleur
N/A
Shift Levers
SRAM XX1 Eagle,12-speed
Cassette
SRAM XG 1295 Eagle, 10-50 tooth, 12-speed
Crank
SRAM XX1 Eagle,12-speed
Bottom Bracket
SRAM PF30 MTB
Chain
SRAM X01 Eagle, 12-speed, black
Chain Guide
None
Pedals
None
Wheels
Front Hub
DT Swiss XRC 1200 Spline wheelset
Rear Hub
DT Swiss XRC 1200 Spline wheelset
Rims
DT Swiss XRC 1200 Spline wheelset, 25mm
Spokes
DT Swiss
Tires
Maxxis Ikon 2.2", 3C, TR, EXO
Brakes
Brakes
Front: SRAM Level Ultimate, 180mm rotor, Rear: SRAM Level Ultimate, 160mm rotor
Brake Levers
SRAM Level Ultimate
Cockpit
Stem
Race Face Turbine 35mm
Handlebar
Race Face Next SL Carbon, 760mm, 10mm rise
Grips
Ergon GA30, Lock-on
Headset
Angular sealed cartridge bearings
Seat
Saddle
SDG Duster RL
Seatpost
Race Face Next, 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.56 mm | 1.48 mm | 1.45 mm | 1.42 mm |
| Bottom Bracket Height | 305 mm | 303 mm | 303 mm | 303 mm | 303 mm |
| Stack | 585 mm | 613.1 mm | 614.2 mm | 629.4 mm | 644.7 mm |
| Reach | 376 mm | 391.9 mm | 415.7 mm | 435.2 mm | 455.5 mm |
| Top Tube Length | 543 mm | 570 mm | 597 mm | 624 mm | 652 mm |
| Seat Tube Angle | 74 ° | 73.75 ° | 73.5 ° | 73.25 ° | 73 ° |
| Seat Tube Length | 368 mm | 405 mm | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 69.5 ° | 70.25 ° | 70.5 ° | 70.75 ° | 71 ° |
| Head Tube Length | 100 mm | 90 mm | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 424 mm | 437 mm | 439 mm | 442 mm | 444 mm |
| Wheelbase | 1040 mm | 1066 mm | 1090 mm | 1115 mm | 1140 mm |
| Bottom Bracket Drop | 50 mm | 52 mm | 52 mm | 52 mm | 52 mm |
| Standover Height | 727 mm | 747 mm | 787 mm | 814 mm | 843 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Revolver HT XX1 belongs to the Norco Revolver model. There are 148 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Norco Revolver HT 3 2019 is the cheapest bike model and costs 2199$. Norco Revolver HT XX1 29 2019 is the most expensive one and costs 6899$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Norco Revolver HT XX1 price was 6899$. If we compare this with the average Crosscountry bike cost we notice that the price is 262.15% more expensive.
Revolver HT XX1 components
Fork
The fork installed on this bike is the RockShox SID model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When leaving the production line, the Revolver HT XX1 model has 27.5″ carbon wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Revolver HT XX1 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
