Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 24" -
Travel Front 80mm -
Fork RST
-
Suspension Hardtail -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco Ryde 24, Chromoly Steel, 10x135mm Tapered Horizontal Dropouts for 3/8" Nutted Axle
Suspension Fork
RST Dirt, 80mm Travel, 9x100mm Nutted Axle
Rear Shock
N/A
Drivetrain
Rear Derailleur
None
Front Derailleur
None
Shift Levers
None
Cassette
Threaded 14T Freewheel
Crank
Three Piece Tubular Chromo, 8 Spline, 170mm
Bottom Bracket
Sealed Mid BB
Chain
KMC Z410A, BMX
Chain Guide
None
Chain Tensioner
Norco 28T Sprocket
Pedals
VP Grind
Wheels
Front Hub
Norco Alloy Disc Hub 36H
Rear Hub
Norco Alloy Disc, 10x135mm
Rims
Alex MUS30, 32 Hole, 23.5mm Internal Width
Spokes
Stainless steel 14g, black
Tires
Kenda K-Rad, 24x2.3"
Brakes
Brakes
Tektro Aires MD-M300, 2 Piston Mechanical Disc, 160mm Rotor
Brake Levers
Tektro Alloy
Cockpit
Stem
Norco Alloy 35mm Stem
Handlebar
Norco 6061 double butted alloy 740mm x 38mm
Grips
Norco Small Flange Grip, Black
Headset
FSA No 8 D Integrated headset
Seat
Saddle
Norco One Piece Saddle
Seatpost
Integrated with Saddle, 25.4mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SINGLE |
|---|---|
| Stack Reach Ratio | 1.5 mm |
| Bottom Bracket Height | 300 mm |
| Front Center | 584 mm |
| Rake | 45 mm |
| Stack | 534 mm |
| Reach | 355 mm |
| Top Tube Length | 539 mm |
| Seat Tube Angle | 71 ° |
| Seat Tube Length | 280 mm |
| Head Tube Angle | 71 ° |
| Head Tube Length | 110 mm |
| Chainstay Length | 366 mm |
| Wheelbase | 950 mm |
| Bottom Bracket Drop | 10 mm |
| Standover Height | 695 mm |
| Wheels | 24" |
| Rider Min Height | 120 cm |
About this model
Ryde 24 completes the Norco Ryde model. Norco released 20 bikes variations of this model so far. Take a sneak peek at all Norco Ryde bikes models from 2019, by clicking here.
Model range prices
The most economical model, the Norco Ryde 24 2019 has a starting price of 525$. Norco Ryde 26 2019 on the other hand is the most expensive at 525$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Dirt Jump bikes average price
According to our math, the average price for a trustworthy Dirt Jump bike is 863$. However, even if your budget is less than the average, you might still be able to get a top-quality Dirt Jump bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2019 for 525$. In conclusion, this bike price is 64.38% smaller than the price of the average Dirt Jump bike.
Ryde 24 components
Fork
The RST is included from the factory. It has a travel distance of 80mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The Ryde 24 2019 bike is equipped with 24″ aluminum wheels when leaving the factory. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
When you want to stop the bike in time, the brakes are vital. The Ryde 24 has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
