Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Aluminum -
Wheels 20" -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Coaster
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Lightweight aluminum low standover frame
Suspension Fork
MTB style long radius w/V-Brake mounts
Rear Shock
N/A
Drivetrain
Rear Derailleur
N/A
Front Derailleur
N/A
Shift Levers
N/A
Cassette
16T BMX type sprocket
Crank
Aluminum narrow-wide 30T 3-pc crankset - Black
Bottom Bracket
Cartridge bearing square taper BB
Pedals
Resin black Jr. BMX flat pedal 1/2" w/bearing"
Wheels
Front Hub
36H MTB hub w/ball bearing
Rear Hub
Coaster brake w/18T sprocket
Rims
Aluminum 20" MTB"
Tires
20" x 2.125"" with MTB tread"
Brakes
Brakes
Tektro alloy V-Brake with linear spring
Brake Levers
Tektro Jr. MTB alloy front and rear levers w/reach adjust
Cockpit
Stem
Kalloy 35mm ext., 1-1/8" threadless MTB"
Handlebar
Jr. MTB 540mm wide x 30mm rise
Grips
Jr. MTB type, soft krayton rubber, 120mm length
Seat
Saddle
Norco Jr. saddle w/ cutaway
Seatpost
Aluminum with micro adjust top, 200mmx27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | N/A |
|---|---|
| Stack Reach Ratio | 1.39 mm |
| Bottom Bracket Height | 255 mm |
| Front Center | 453 mm |
| Rake | 21 mm |
| Stack | 389 mm |
| Reach | 280 mm |
| Top Tube Length | 448 mm |
| Seat Tube Angle | 67 ° |
| Seat Tube Length | 240 mm |
| Head Tube Angle | 70 ° |
| Head Tube Length | 90 mm |
| Chainstay Length | 341 mm |
| Wheelbase | 793 mm |
| Bottom Bracket Drop | 5 mm |
| Standover Height | 463 mm |
| Wheels | 20" |
About this model
Samurai 20″ belongs to the Norco Samurai model. Norco released 14 frames variations of this model so far. Take a sneak peek at all Norco Samurai frames models from 2017, by clicking here.
Model range prices
Norco Samurai 20″ 2017 is the most economical model, with a starting price of 239$. Norco Samurai 16″ 2017 on the other hand costs 259$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Mountain frames
According to our calculations, the average cost of a Mountain frame that is reliable is 514$. However, this doesn’t mean that if you spend less money on a Mountain frame, you couldn’t get a decent one. To sum up, when you purchase your frame, make sure to check if it has reviews, and also do some components research.
This frame was released in 2017 and its price was 239$. Comparing the average cost of a Mountain frame to this one, you will see that Samurai 20″ price is 115.06% smaller.
Samurai 20″ components
Brakes
Stopping the bike when needed, it’s essential for your safety. This frame has Coaster brakes. These brakes are pretty efficient, and they’re not so pricey. However, if your chain falls off or snaps, your coaster brakes won’t function anymore.
