Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Groupset Tourney -
Suspension Rigid -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
7005 ALLOY FRAME
Suspension Fork
ALLOY BLADE, CR-MO STEER
Rear Shock
N/A
Drivetrain
Rear Derailleur
SHIMANO TX-51
Front Derailleur
N/A
Shift Levers
N/A
Cassette
SHIMANO TZ-21 14-28
Crank
STEEL 170MM 44 TOOTH
Bottom Bracket
MTB SQUARE TAPER
Chain
KMC Z50
Pedals
VP 9/16
Wheels
Front Hub
STEEL NUTTED
Rear Hub
STEEL NUTTED
Rims
ALLOY SILVER
Spokes
STAINLESS 14G
Tires
26 X 2.125
Brakes
Brakes
TEKTRO ALLOY
Brake Levers
TEKTRO ALLOY
Cockpit
Stem
ALLOY QUILL 80MM EXTENSION
Handlebar
ALLOY SWEPT BACK SILVER
Grips
VELO CORK
Headset
STEEL 1-1/8
Seat
Saddle
VELO CUSTOM
Seatpost
ALLOY 27.2 X 250MM
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | N/A |
|---|---|
| Stack Reach Ratio | 1.46 mm |
| Bottom Bracket Height | 287 mm |
| Front Center | 664 mm |
| Rake | 45 mm |
| Trail | 80 mm |
| Stack | 581 mm |
| Reach | 397 mm |
| Top Tube Length | 644 mm |
| Seat Tube Angle | 67 ° |
| Seat Tube Length | 450 mm |
| Head Tube Angle | 68 ° |
| Head Tube Length | 180 mm |
| Chainstay Length | 514 mm |
| Wheelbase | 1173 mm |
| Bottom Bracket Drop | 50 mm |
| Standover Height | 618 mm |
| Wheels | 26" |
| Rider Min Height | 120 cm |
Model Overview
Santiago W is part of the Norco Santiago model. Norco launched 22 bikes of this model so far. You can get a glimpse at all models from 2012, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Cruiser bikes average price
Our math shows that the average cost of a dependable Cruiser bike is 332$. However, even if your budget is less than the average, you might still be able to get a top-quality Cruiser bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Santiago W components
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
As for the wheels, Norco Santiago W 2012, has a 26″ aluminum model. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
