Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Search X6 Double Butted Aluminum - Disc
Suspension Fork
Search Mid-Mod Full Carbon - TA Disc
Drivetrain
Rear Derailleur
Shimano Tiagra RD-4700
Front Derailleur
Shimano Tiagra FD-4700
Shift Levers
N/A
Cassette
Shimano Tiagra CS-4700 11-32T 10 speed
Crank
Shimano Tiagra FC-R4700 50/34T - Black
Bottom Bracket
Shimano HollowTech II
Chain
KMX X10
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
Alloy 15x100mm Thru-Axle Disc 28h - Black
Rear Hub
Alloy 10x135mm QR 28h - Black
Rims
Aero double wall alloy - Black
Tires
Schwalbe Tyrago 700x35c w/Reflex
Brakes
Brakes
TRP Spyre Twin Piston Mechanical Disc - 160mm
Brake Levers
Shimano Tiagra ST-4700
Disk Rotors
N/A
Cockpit
Stem
Norco - Black Stealth
Handlebar
Norco Flare - Black
Grips
Norco Ultra Comfort ShockProof - Black
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
Norco Sport - Black
Seatpost
Norco 27.2mm - Black Stealth
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45.5cm | 48cm | 50.5cm | 53cm | 55.5cm | 58cm | 60.5cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.445 mm | 1.469 mm | 1.495 mm | 1.521 mm | 1.537 mm | 1.568 mm |
| Bottom Bracket Height | 270 mm | 272.5 mm | 272.5 mm | 275 mm | 275 mm | 277.5 mm | 277.5 mm |
| Front Center | 572 mm | 582 mm | 588 mm | 592 mm | 604 mm | 617 mm | 629 mm |
| Rake | 49 mm | 49 mm | 49 mm | 48 mm | 49 mm | 49 mm | 49 mm |
| Trail | 72 mm | 70 mm | 67 mm | 63 mm | 60 mm | 59 mm | 57 mm |
| Stack | 517 mm | 529 mm | 545 mm | 562 mm | 584 mm | 604 mm | 627 mm |
| Reach | 359 mm | 366 mm | 371 mm | 376 mm | 384 mm | 393 mm | 400 mm |
| Top Tube Length | 497.5 mm | 510 mm | 525 mm | 542.5 mm | 560 mm | 577.5 mm | 595 mm |
| Seat Tube Angle | 75 ° | 74.75 ° | 74.25 ° | 73.5 ° | 73.25 ° | 73 ° | 72.75 ° |
| Seat Tube Length | 400 mm | 425 mm | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm |
| Head Tube Angle | 70.5 ° | 70.75 ° | 71.25 ° | 72 ° | 72.25 ° | 72.5 ° | 72.75 ° |
| Head Tube Length | 100 mm | 115 mm | 130 mm | 147.5 mm | 170 mm | 192.5 mm | 215 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 986 mm | 996 mm | 1002 mm | 1006 mm | 1019 mm | 1033 mm | 1045 mm |
| Bottom Bracket Drop | 75 mm | 72 mm | 72 mm | 70 mm | 70 mm | 67 mm | 67 mm |
| Standover Height | 700 | 720 mm | 738 mm | 760 mm | 788 mm | 814 mm | 837 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Search A Tiagra completes the Norco Search model. There are 121 bikes that carry this model name. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
Norco Search A Sora 2017 is the most economical model, with a starting price of 1045$. Norco Search C Ultegra 2017 on the other hand costs 3450$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Norco Search A Tiagra price was 1199$. Doing a quick comparison, we notice that Search A Tiagra price is 105.34% smaller than the average cost of a Gravel bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
As for the wheels, Norco Search A Tiagra 2017, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Search A Tiagra has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
