Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 700c -
Suspension Rigid
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Search Carbon
Suspension Fork
Search Carbon
Cockpit
Headset
Angular Sealed Cartridge Bearings - Tapered
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45.5cm | 48cm | 50.5cm | 53cm | 55.5cm | 58cm | 60.5cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.437 mm | 1.46 mm | 1.484 mm | 1.495 mm | 1.523 mm | 1.537 mm | 1.568 mm |
| Bottom Bracket Height | 280 mm | 280 mm | 280 mm | 282 mm | 282 mm | 285 mm | 285 mm |
| Front Center | 572 mm | 584 mm | 588 mm | 591 mm | 604 mm | 617 mm | 629 mm |
| Rake | 49 mm | 54 mm | 52 mm | 48 mm | 49 mm | 49 mm | 49 mm |
| Trail | 72 mm | 65 mm | 64 mm | 63 mm | 60 mm | 59 mm | 57 mm |
| Stack | 516 mm | 530 mm | 546 mm | 562 mm | 585 mm | 604 mm | 627 mm |
| Reach | 359 mm | 363 mm | 368 mm | 376 mm | 384 mm | 393 mm | 400 mm |
| Top Tube Length | 498 mm | 513 mm | 525 mm | 543 mm | 560 mm | 578 mm | 595 mm |
| Seat Tube Angle | 75 ° | 74.75 ° | 74.25 ° | 73.5 ° | 73.25 ° | 73 ° | 72.75 ° |
| Seat Tube Length | 400 mm | 425 mm | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm |
| Head Tube Angle | 70.5 ° | 70.75 ° | 71.25 ° | 72 ° | 72.25 ° | 72.5 ° | 72.75 ° |
| Head Tube Length | 100 mm | 115 mm | 130 mm | 148 mm | 170 mm | 193 mm | 215 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 985 mm | 998 mm | 1002 mm | 1006 mm | 1019 mm | 1033 mm | 1045 mm |
| Bottom Bracket Drop | 75 mm | 73 mm | 72 mm | 70 mm | 70 mm | 67 mm | 67 mm |
| Standover Height | 708 mm | 720 mm | 737 mm | 763 mm | 785 mm | 808 mm | 833 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Search C Frame/Fork is a Norco Search model. Norco released 121 frames variations of this model so far. You can get a glimpse at all models from 2018, by clicking on this link.
Model range prices
Norco Search XR-S Frame/Fork 700c 2018 is the cheapest frame model and costs 899$. Norco Search XR Frame/Fork 2018 is the most expensive one and costs 1999$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Gravel frames average price
According to our calculations, the average cost of a Gravel frame that is reliable is 1505$. However, this doesn’t mean that if you spend less money on a Gravel frame, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the frame and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Norco Search C Frame/Fork price was 1499$. Doing a quick comparison, we notice that Search C Frame/Fork price is 0.4% lower than the average cost of a Gravel frame.
Search C Frame/Fork components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
