Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
50.5cm
158cm - 167cm
53cm
165cm - 174cm
55.5cm
171cm - 180cm
58cm
177cm - 186cm
60.5cm
184cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Butted X6 Aluminum
Suspension Fork
Search XR Carbon
Drivetrain
Rear Derailleur
Shimano GRX RD-RX810 Shadow RD+
Front Derailleur
Shimano GRX FD-RX810
Shift Levers
Shimano GRX ST-RX600
Cassette
Shimano 105 CS-R7000, 11-34T, 11 Speed
Crank
Shimano GRX FC-RX600, 46/30T, 170mm (50.5), 172.5mm (53, 55.5), 175mm (58, 60.5)
Bottom Bracket
Shimano BB-RS500 PF86
Chain
KMC X11
Wheels
Front Hub
Shimano HB-RS470, 12x100mm, Center Lock
Rear Hub
Shimano FH-RS470, 12x142mm, HG, Center Lock
Rims
WTB ST i23 TCS 2.0 32H, 650b (45.5, 48), 700c (50.5-60.5)
Tires
Front: Vittoria Terreno Dry, 38mm, Rear: Vittoria Terreno Dry, 38mm
Brakes
Brakes
Front: Shimano GRX BR-RX400 Hydraulic Disc, Resin Pads, Rear: Shimano GRX BR-RX400 Hydraulic Disc, Resin Pads
Brake Levers
Shimano GRX RX600 Hydraulic
Cockpit
Stem
Norco SL Aluminum
Handlebar
Norco Super Flare Aluminum, 16deg Flare, 42cm (45.5, 48, 50.5), 44cm (53, 55.5), 46cm (58, 60.5)
Grips
Norco Griptacular Shockproof Tape
Headset
Integrated Sealed Bearing
Seat
Saddle
Selle Royal Vivo, Mag Rails
Seatpost
Norco Aluminum, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50.5cm | 53cm | 55.5cm | 58cm | 60.5cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.42 mm | 1.46 mm | 1.48 mm | 1.5 mm |
| Bottom Bracket Height | 279 mm | 282 mm | 282 mm | 284 mm | 284 mm |
| Front Center | 615 mm | 618 mm | 623 mm | 637 mm | 649 mm |
| Rake | 49 mm | 49 mm | 49 mm | 49 mm | 49 mm |
| Trail | 70 mm | 67 mm | 65 mm | 63 mm | 62 mm |
| Stack | 539 mm | 555 mm | 572 mm | 592 mm | 612 mm |
| Reach | 388 mm | 390 mm | 392 mm | 401 mm | 409 mm |
| Top Tube Length | 542 mm | 554.5 mm | 567 mm | 584.5 mm | 602 mm |
| Seat Tube Angle | 74.25 ° | 73.75 ° | 73.25 ° | 73 ° | 72.75 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.75 ° | 72 ° | 72.25 ° |
| Head Tube Length | 120 mm | 137.5 mm | 155 mm | 177.5 mm | 197.5 mm |
| Chainstay Length | 414 mm | 414 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 1018 mm | 1022 mm | 1030 mm | 1044 mm | 1056 mm |
| Bottom Bracket Drop | 75 mm | 72 mm | 72 mm | 70 mm | 70 mm |
| Standover Height | 679 mm | 709 mm | 736 mm | 766 mm | 794 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 165 cm | 171 cm | 177 cm | 184 cm |
| Rider Max Height | 167 cm | 174 cm | 180 cm | 186 cm | 194 cm |
Model Overview
Search XR A1 completes the Norco Search model. Norco released 121 bikes variations of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
The most economical model, the Norco Search XR Flat Bar 2022 has a starting price of 1299$. Norco Search XR C 700c 2022 on the other hand is the most expensive at 3999$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2022 for 2099$. In conclusion, this bike price is 17.29% lower than the price of the average Gravel bike.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When it comes to wheels, the Search XR A1 bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Search XR A1 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Norco Search XR A1 bike has 5 sizes, in the range of 158 cm – 194 cm (5.18 ft – 6.36 ft). In short, it won’t be difficult to find the right one for you.
