Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
45.5cm
147cm - 154cm
48cm
152cm - 161cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Butted Aluminum, Smooth Welds
Suspension Fork
Full Carbon, Through Axle
Drivetrain
Rear Derailleur
Shimano GRX RD-RX810 Shadow RD+
Front Derailleur
Shimano GRX FD-RX810
Shift Levers
Shimano GRX ST-RX600
Cassette
Shimano 105 CS-R7000, 11-34T, 11 Speed
Crank
FSA Omega Modular 46/30 AGX+, 170mm (49, 52cm), 172.5mm (55, 58cm), 175mm (61cm)
Bottom Bracket
FSA BB386EVO for BSA
Chain
KMC X11
Pedals
City Resin
Wheels
Front Hub
Bear Pawls Sealed Bearing, 12x100mm, 6 bolt
Rear Hub
Bear Pawls Sealed Bearing, 12x142mm, HG, 6 Bolt
Rims
Alloy Pinned, 28H, 23mm ID
Tires
Front: Vittoria Terreno Dry 700x40c Graphene 2.0, Rear: Vittoria Terreno Dry 700x40c Graphene 2.0
Brakes
Brakes
Front: Shimano GRX BR-RX400, Resin Pads, Rear: Shimano GRX BR-RX400, Resin Pads
Brake Levers
Shimano GRX RX600
Cockpit
Stem
Norco SL Aluminum, 31.8mm Clamp, 70mm (49), 80mm (52), 90mm (55), 100mm (58), 110mm (61)
Handlebar
Norco Super Flare Aluminum, 16 Degree Flare, 40cm (49), 42cm (52), 44cm (55), 46cm (58, 61)
Grips
Griptacular Shockproof Tape
Headset
Sealed Cartridge Bearing
Seat
Saddle
Selle Royal Gravel with Cutout
Seatpost
Aluminum 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45.5cm | 48cm |
|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm |
| Bottom Bracket Height | 275 mm | 275 mm |
| Front Center | 567 mm | 578 mm |
| Rake | 49 mm | 49 mm |
| Trail | 64 mm | 62 mm |
| Stack | 497 mm | 517 mm |
| Reach | 348 mm | 355 mm |
| Top Tube Length | 493 mm | 508 mm |
| Seat Tube Angle | 74 ° | 73.75 ° |
| Seat Tube Length | 410 mm | 435 mm |
| Head Tube Angle | 70.75 ° | 71 ° |
| Head Tube Length | 110 mm | 130 mm |
| Chainstay Length | 403 mm | 403 mm |
| Wheelbase | 963 mm | 974 mm |
| Bottom Bracket Drop | 57 mm | 57 mm |
| Standover Height | 628 mm | 651 mm |
| Wheels | 650 | 650 |
| Rider Min Height | 147 cm | 152 cm |
| Rider Max Height | 154 cm | 161 cm |
Model Overview
Search XR A1 650b is part of the Norco Search model. 121 bikes variations carry this model name so far. Take a sneak peek at all Norco Search bikes models from 2022, by clicking here.
Model range prices
The most economical model, the Norco Search XR Flat Bar 2022 has a starting price of 1299$. Norco Search XR C 700c 2022 on the other hand is the most expensive at 3999$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2099$. Comparing this to the average Gravel bike price, we see that the price is 17.29% lower.
Overview of components
Fork material
Search XR A1 650b has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the Search XR A1 650b model has aluminum wheels. After 700c wheels, 650b is the second most popular choice for road bikes. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
When you want to stop the bike in time, the brakes are vital. The Search XR A1 650b has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Norco Search XR A1 650b bike has 2 sizes, in the range of 147 cm – 161 cm (4.82 ft – 5.28 ft). In short, you can easily find one that suits you.
