Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 400, Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
50.5cm
158cm - 167cm
53cm
165cm - 174cm
55.5cm
171cm - 180cm
58cm
177cm - 186cm
60.5cm
184cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Butted X6 Aluminum
Suspension Fork
Search XR Carbon
Drivetrain
Rear Derailleur
Shimano GRX RD-RX400 Shadow RD+
Front Derailleur
Shimano GRX FD-RX400
Shift Levers
Shimano Tiagra ST-4700
Cassette
Shimano CS-HG50, 11-36T, 10 Speed
Crank
Shimano GRX FC-RX600, 46/30T, 170mm (50.5), 172.5mm (53, 55.5), 175mm (58, 60.5)
Bottom Bracket
Shimano BB-RS500 PF86
Chain
KMC X10
Wheels
Front Hub
Alloy 12x100mm, 6 Bolt
Rear Hub
Alloy 12x142mm, HG, 6 Bolt
Rims
WTB ST i23 TCS 2.0 32H, 650b (45.5, 48), 700c (50.5-60.5)
Tires
Front: Vittoria Terreno Dry, 38mm, Rear: Vittoria Terreno Dry, 38mm
Brakes
Brakes
Front: Tektro MD-C550 Dual-Piston Mechanical Disc, Rear: Tektro MD-C550 Dual-Piston Mechanical Disc
Brake Levers
Shimano Tiagra ST-4700
Cockpit
Stem
Norco SL Aluminum
Handlebar
Norco Super Flare Aluminum, 16deg Flare, 42cm (45.5, 48, 50.5), 44cm (53, 55.5), 46cm (58, 60.5)
Grips
Norco Griptacular Shockproof Tape
Headset
Integrated Sealed Bearing
Seat
Saddle
Selle Royal Vivo, Mag Rails
Seatpost
Norco Aluminum, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50.5cm | 53cm | 55.5cm | 58cm | 60.5cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.42 mm | 1.46 mm | 1.48 mm | 1.5 mm |
| Bottom Bracket Height | 279 mm | 282 mm | 282 mm | 284 mm | 284 mm |
| Front Center | 615 mm | 618 mm | 623 mm | 637 mm | 649 mm |
| Rake | 49 mm | 49 mm | 49 mm | 49 mm | 49 mm |
| Trail | 70 mm | 67 mm | 65 mm | 63 mm | 62 mm |
| Stack | 539 mm | 555 mm | 572 mm | 592 mm | 612 mm |
| Reach | 388 mm | 390 mm | 392 mm | 401 mm | 409 mm |
| Top Tube Length | 542 mm | 554.5 mm | 567 mm | 584.5 mm | 602 mm |
| Seat Tube Angle | 74.25 ° | 73.75 ° | 73.25 ° | 73 ° | 72.75 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.75 ° | 72 ° | 72.25 ° |
| Head Tube Length | 120 mm | 137.5 mm | 155 mm | 177.5 mm | 197.5 mm |
| Chainstay Length | 414 mm | 414 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 1018 mm | 1022 mm | 1030 mm | 1044 mm | 1056 mm |
| Bottom Bracket Drop | 75 mm | 72 mm | 72 mm | 70 mm | 70 mm |
| Standover Height | 679 mm | 709 mm | 736 mm | 766 mm | 794 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 165 cm | 171 cm | 177 cm | 184 cm |
| Rider Max Height | 167 cm | 174 cm | 180 cm | 186 cm | 194 cm |
Model Overview
Search XR A2 completes the Norco Search model. Norco launched 121 bikes of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
The most economical model, the Norco Search XR Flat Bar 2022 has a starting price of 1299$. Norco Search XR C 700c 2022 on the other hand is the most expensive at 3999$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Norco Search XR A2 price was 1649$. Comparing this to the average Gravel bike price, we see that the price is 49.3% lower.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When it comes to wheels, the Search XR A2 bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Search XR A2 is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Search XR A2 comes in 5 sizes, that range from 158 cm – 194 cm (5.18 ft – 6.36 ft). In short, you can easily find one that suits you.
