Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Groupset GRX 400, Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Double Butted X6 Aluminum, Smooth Welds
Suspension Fork
Mid-Modulus Carbon
Drivetrain
Rear Derailleur
Shimano GRX RD-RX400
Front Derailleur
Shimano GRX FD-RX400
Shift Levers
Rear: Shimano Tiagra ST-4700 10 speed, Front: Shimano Tiagra ST-4700 2 speed
Cassette
Shimano CS-HG50 11-36T
Crank
Shimano GRX FC-RX600 46/30T
Bottom Bracket
Shimano BB-RS500 PressFit BB86
Chain
KMC X10
Wheels
Front Hub
12x100mm TA 32h - Black
Rear Hub
12x142mm TA 32h - Black
Rims
WTB ST i23 TCS 2.0
Tires
Schwalbe G-One Bite 700x38c Raceguard - Folding
Brakes
Brakes
Tektro MD-C550 Dual-Piston Mechanical Disc
Brake Levers
Shimano Tiagra ST-4700
Cockpit
Stem
Norco SL Aluminum
Handlebar
Norco Super Flare Aluminum, 16deg Flare
Headset
Integrated Sealed Cartridge Bearings
Seat
Saddle
Norco Race, Chromo Rails
Seatpost
Norco SL Aluminum
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45.5cm | 48cm |
|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm |
| Bottom Bracket Height | 275 mm | 275 mm |
| Front Center | 567 mm | 578 mm |
| Rake | 49 mm | 49 mm |
| Trail | 64 mm | 62 mm |
| Stack | 497 mm | 517 mm |
| Reach | 348 mm | 355 mm |
| Top Tube Length | 493 mm | 508 mm |
| Seat Tube Angle | 74 ° | 73.75 ° |
| Seat Tube Length | 410 mm | 435 mm |
| Head Tube Angle | 70.75 ° | 71 ° |
| Head Tube Length | 110 mm | 130 mm |
| Chainstay Length | 403 mm | 403 mm |
| Wheelbase | 963 mm | 974 mm |
| Bottom Bracket Drop | 57 mm | 57 mm |
| Standover Height | 628 mm | 651 mm |
| Wheels | 650 | 650 |
About this model
Search XR A2 650b is a Norco Search model. There are 121 bikes that carry this model name. Take a sneak peek at all Norco Search bikes models from 2020, by clicking here.
Model range prices
Norco Search XR A2 700c 2020 is the most affordable bike of this model and has a price of 1599$. On the other hand, Norco Search XR C SE 700c 2020, is the most expensive and costs 5999$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Norco Search XR A2 650b price was 1599$. Doing a quick comparison, we notice that Search XR A2 650b price is 53.97% lower than the average cost of a Gravel bike.
Overview of components
Fork material
Search XR A2 650b has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When it comes to wheels, the Search XR A2 650b bike is equipped with the aluminum model. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Search XR A2 650b comes with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
