Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
High-Modulus Carbon
Suspension Fork
Mid-Modulus Carbon
Drivetrain
Rear Derailleur
Shimano GRX RD-RX810
Front Derailleur
Shimano GRX FD-RX810
Shift Levers
Rear: Shimano GRX ST-RX600 11 speed, Front: Shimano GRX ST-RX600 2 speed
Cassette
Shimano 105 CS-R7000 11-34T
Crank
Shimano GRX FC-RX600 46/30T
Bottom Bracket
Shimano BB-RS500 PressFit BB86
Chain
KMC X11
Wheels
Front Hub
Shimano HB-RS470 - 12x100mm TA
Rear Hub
Shimano FH-RS470 - 12x142mm TA
Rims
WTB ST Light i23 TCS 2.0, Tubeless Ready
Tires
WTB Resolute TCS 700x42c, Tubeless Compatible System, Tanwall
Brakes
Brakes
Shimano GRX BR-RX400 Hydraulic Disc
Brake Levers
Shimano GRX RX600 Hydraulic
Cockpit
Stem
Norco SL Aluminum
Handlebar
Norco Super Flare Aluminum, 16deg Flare
Headset
FSA Orbit No. 42
Seat
Saddle
Norco SL Race, Cromo Rails
Seatpost
X-Fusion Manic Gravel 50mm Dropper, Drop-Bar Remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50.5cm | 53cm | 55.5cm | 58cm | 60.5cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.48 mm | 1.5 mm | 1.51 mm | 1.53 mm |
| Bottom Bracket Height | 277 mm | 280 mm | 280 mm | 282 mm | 282 mm |
| Front Center | 595 mm | 603 mm | 614 mm | 627 mm | 639 mm |
| Rake | 49 mm | 49 mm | 49 mm | 49 mm | 49 mm |
| Trail | 69 mm | 66 mm | 64 mm | 63 mm | 61 mm |
| Stack | 539 mm | 555 mm | 572 mm | 592 mm | 612 mm |
| Reach | 368 mm | 375 mm | 382 mm | 391 mm | 399 mm |
| Top Tube Length | 522 mm | 540 mm | 557 mm | 575 mm | 592 mm |
| Seat Tube Angle | 74.25 ° | 73.75 ° | 73.25 ° | 73 ° | 72.75 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.75 ° | 72 ° | 72.25 ° |
| Head Tube Length | 120.9 mm | 137.5 mm | 155 mm | 177.5 mm | 197.5 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 417 mm | 417 mm |
| Wheelbase | 998 mm | 1007 mm | 1018 mm | 1034 mm | 1046 mm |
| Bottom Bracket Drop | 75 mm | 72 mm | 72 mm | 70 mm | 70 mm |
| Standover Height | 678 mm | 709 mm | 736 mm | 767 mm | 794 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Search XR C3 700c belongs to the Norco Search model. There are 121 bikes that carry this model name. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Norco Search XR A2 700c 2020 is the cheapest bike model and costs 1599$. Norco Search XR C SE 700c 2020 is the most expensive one and costs 5999$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3299$. In conclusion, this bike price is 34% more expensive than the price of the average Gravel bike.
Overview of components
Fork material
Search XR C3 700c has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The wheels on Search XR C3 700c are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Search XR C3 700c has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Dropper post
Norco Search XR C3 700c includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
