Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 650b / 700c -
Groupset Force 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Search XR Carbon
Suspension Fork
Search XR Carbon
Drivetrain
Rear Derailleur
SRAM Force 1 Long Cage
Front Derailleur
Norco Integrated 1x Guide
Shift Levers
Rear: SRAM Force 1 11spd w/Hydro Disc, Front: SRAM Force 1 Modified Dropper Remote w/Hydro Disc
Cassette
SRAM XG-1180 11speed 10-42T
Crank
Quarq Prime Carbon 1 X-Sync 40T - Power Ready
Bottom Bracket
Enduro GXP Pressfit86
Chain
SRAM PC-1170
Wheels
Front Hub
DT Swiss 350 12x100mm Thru-Axle 28h - Black
Rear Hub
DT Swiss 350 12x142mm Thru-Axle 28h - Black
Rims
WTB Frequency Team i23 - Black
Tires
Maxxis Tread Lite 26x 2.1”(45.5/48) or 650Bx2.1”(50.5-60.5) – Folding/Tubeless
Brakes
Brakes
SRAM Force 1 Hydraulic Disc Brake w/160mm
Brake Levers
SRAM Force 1 Hydraulic Disc Brake
Cockpit
Stem
Norco SL Alloy - Black
Handlebar
Easton EC70 AX w/16deg Flare
Grips
Norco Super Griptacular w/Gel - Black
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
WTB Volt Team w/Ti Rails - Black
Seatpost
KS LEV Integra Dropper Post - 27.2mm - 65mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45.5cm | 48cm | 50.5cm | 53cm | 55.5cm | 58cm | 60.5cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm | 1.46 mm | 1.48 mm | 1.5 mm | 1.51 mm | 1.53 mm |
| Bottom Bracket Height | 278 mm | 278 mm | 270 mm | 272.5 mm | 272.5 mm | 275 mm | 275 mm |
| Front Center | 566 mm | 578 mm | 595 mm | 604 mm | 614 mm | 627 mm | 639 mm |
| Rake | 50 mm | 49 mm | 49 mm | 49 mm | 50 mm | 49 mm | 49 mm |
| Trail | 62 mm | 62 mm | 68 mm | 65 mm | 62 mm | 62 mm | 60 mm |
| Stack | 497 mm | 517 mm | 540 mm | 556 mm | 573 mm | 593 mm | 613 mm |
| Reach | 348 mm | 355 mm | 369 mm | 376 mm | 383 mm | 392 mm | 400 mm |
| Top Tube Length | 493 mm | 508 mm | 523 mm | 541 mm | 558 mm | 576 mm | 593 mm |
| Seat Tube Angle | 74 ° | 73.75 ° | 74.25 ° | 73.75 ° | 73.25 ° | 73 ° | 72.75 ° |
| Seat Tube Length | 410 mm | 435 mm | 460 mm | 490 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 70.75 ° | 71 ° | 71 ° | 71.5 ° | 71.75 ° | 72 ° | 72.25 ° |
| Head Tube Length | 110 mm | 130 mm | 120 mm | 138 mm | 155 mm | 178 mm | 198 mm |
| Chainstay Length | 403 mm | 403 mm | 415 mm | 415 mm | 415 mm | 418 mm | 418 mm |
| Wheelbase | 963 mm | 974 mm | 999 mm | 1008 mm | 1019 mm | 1035 mm | 1047 mm |
| Bottom Bracket Drop | 57 mm | 57 mm | 75 mm | 73 mm | 73 mm | 70 mm | 70 mm |
| Standover Height | 699 mm | 718 mm | 731 mm | 753 mm | 774 mm | 799 mm | 822 mm |
| Wheels | 650 | 650 | 700 | 700 | 700 | 700 | 700 |
About this model
Search XR Force 1 is part of the Norco Search model. Norco launched 121 bikes of this model so far. You can easily view all of the Norco Search bikes models from 2018, here.
Model range prices
Norco Search A Claris 2018 is the most economical model, with a starting price of 749$. Norco Search XR Force 1 2018 on the other hand costs 4199$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Norco released this model in 2018, its price was 4199$. In conclusion, this bike price is 70.55% higher than the price of the average Gravel bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When leaving the production line, the Search XR Force 1 model has aluminum wheels. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Search XR Force 1 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Dropper post
Norco Search XR Force 1 comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
