Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 800, 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Double Butted X6 Aluminum, Smooth Welds
Suspension Fork
Mid-Modulus Carbon
Drivetrain
Rear Derailleur
Shimano GRX RD-RX810
Front Derailleur
Shimano 105 FD-R7000
Shift Levers
Rear: Shimano 105 ST-R7020 11 speed, Front: Shimano 105 ST-R7020 2 speed
Cassette
Shimano 105 CS-R7000 11-32T
Crank
Shimano FC-RS510 50/34T
Bottom Bracket
Shimano HollowTech II Threaded
Chain
KMC X11
Wheels
Front Hub
Shimano HB-RS470 12x100mm TA
Rear Hub
Shimano FH-RS470 12x142mm TA
Rims
WTB ST i21 TCS 2.0
Tires
Schwalbe Durano 700x32c RaceGuard
Brakes
Brakes
Shimano 105 BR-R7020 Hydraulic Disc
Brake Levers
Shimano 105 ST-R7020 Hydraulic
Cockpit
Stem
Norco SL Aluminum
Handlebar
Norco Aero All Road Aluminum,10deg Flare
Headset
Integrated, Sealed Cartridge Bearings
Seat
Saddle
Norco SL Race Chromo Rails
Seatpost
Norco Aluminum
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45.5cm | 48cm | 50.5cm | 53cm | 55.5cm | 58cm | 60.5cm | 63cm |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.423 mm | 1.425 mm | 1.428 mm | 1.44 mm | 1.464 mm | 1.481 mm | 1.501 mm | 1.514 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 271.5 mm | 271.5 mm | 271.5 mm | 274 mm | 274 mm | 274 mm |
| Front Center | 575 mm | 581 mm | 588 mm | 598 mm | 605 mm | 618 mm | 630 mm | 645 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 65 mm | 62 mm | 59 mm | 56 mm | 58 mm | 56 mm | 54 mm | 54 mm |
| Stack | 515 mm | 526 mm | 537 mm | 556 mm | 574 mm | 594 mm | 614 mm | 633 mm |
| Reach | 362 mm | 369 mm | 376 mm | 386 mm | 392 mm | 401 mm | 409 mm | 418 mm |
| Top Tube Length | 500 mm | 515 mm | 530 mm | 548 mm | 565 mm | 583 mm | 600 mm | 615 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.75 ° | 73.25 ° | 73 ° | 72.75 ° | 71.75 ° |
| Seat Tube Length | 400 mm | 425 mm | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm | 595 mm |
| Head Tube Angle | 70.75 ° | 71.25 ° | 71.75 ° | 72.25 ° | 72.5 ° | 72.75 ° | 73 ° | 73 ° |
| Head Tube Length | 97.5 mm | 107.5 mm | 120 mm | 137.5 mm | 155 mm | 177.5 mm | 197.5 mm | 217.5 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 978 mm | 984 mm | 992 mm | 1002 mm | 1009 mm | 1026 mm | 1038 mm | 1053 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 72 mm | 72 mm | 72 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 622 mm | 644 mm | 670 mm | 697 mm | 725 mm | 755 mm | 783 mm | 806 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Section A1 is a Norco Section model. 36 bikes variations carry this model name so far. You can easily view all of the Norco Section bikes models from 2020, here.
Model range prices
The most economical model, the Norco Section A2 Women’s 2020 has a starting price of 1299$. Norco Section C1 2020 on the other hand is the most expensive at 5799$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2020 for 1799$. Comparing this to the average Gravel bike price, we see that the price is 36.85% smaller.
Overview of components
Fork material
Section A1 has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the Section A1 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Section A1 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
