Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco Section, Aluminum, 12x142mm TA Dropouts
Suspension Fork
Norco Section Carbon Fork, 12x100mm TA, Aluminum/Steel Frame Specific
Drivetrain
Rear Derailleur
Shimano 105 RD-R7000-GS, 11 Speed
Front Derailleur
Shimano 105 FD-R7000, 2 Speed
Shift Levers
Rear: Shimano 105 ST-R7020, Hydraulic Brake, 11 Speed, Front: Shimano 105 ST-R7020, Hydraulic Brake, 2 Speed
Cassette
Shimano 105 CS-R7000, 11-32T, 11 Speed
Crank
Shimano FC-RS510, 50/34T
Bottom Bracket
Shimano HollowTech II BB, Threaded BSA 68mm
Chain
KMC X11, 11 Speed
Wheels
Front Hub
Alloy, 28 Hole, 12x100mm TA
Rear Hub
Alloy, 28 Hole, 12x142mm TA
Rims
WTB SpeedDisc i19, 28 Hole, 19mm Internal Width
Tires
Schwalbe Durano, 700x32c, RaceGuard, Folding
Brakes
Brakes
Shimano 105 BR-R7020, Hydraulic Disc, Shimano Center Lock/Ice-Tech 160mm Rotor
Brake Levers
Shimano 105 ST-R7020, Hydraulic
Cockpit
Stem
Norco SL Alloy
Handlebar
Norco Aero All Road, 10° Flare
Headset
Angular Sealed Cartridge Bearings, Tapered
Seat
Saddle
Norco SL Race, Cromo Rails, Brown
Seatpost
Norco SL Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50.5cm | 53cm | 55.5cm | 58cm | 60.5cm | 63cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.44 mm | 1.45 mm | 1.48 mm | 1.49 mm | 1.51 mm | 1.53 mm |
| Bottom Bracket Height | 269 mm | 271.5 mm | 271.5 mm | 271.5 mm | 274 mm | 274 mm | 274 mm |
| Front Center | 581 mm | 587 mm | 598 mm | 605 mm | 618 mm | 630 mm | 645 mm |
| Rake | 51 mm | 51 mm | 50 mm | 48 mm | 48 mm | 48 mm | 49 mm |
| Trail | 65 mm | 61 mm | 59 mm | 60 mm | 58 mm | 57 mm | 55 mm |
| Stack | 517 mm | 528 mm | 547 mm | 565 mm | 585 mm | 605 mm | 624 mm |
| Reach | 360 mm | 367 mm | 377 mm | 383 mm | 392 mm | 400 mm | 409 mm |
| Top Tube Length | 506 mm | 521 mm | 538.5 mm | 556 mm | 573.5 mm | 591 mm | 606 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.75 ° | 73.25 ° | 73 ° | 72.75 ° | 72.75 ° |
| Seat Tube Length | 425 mm | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm | 595 mm |
| Head Tube Angle | 71.25 ° | 71.75 ° | 72.25 ° | 72.5 ° | 72.75 ° | 73 ° | 73 ° |
| Head Tube Length | 107.5 mm | 120 mm | 137.5 mm | 155 mm | 177.5 mm | 197.5 mm | 217.5 mm |
| Chainstay Length | 406 mm | 406 mm | 406 mm | 406 mm | 409 mm | 409 mm | 409 mm |
| Wheelbase | 975 mm | 983 mm | 993 mm | 1000 mm | 1017 mm | 1029 mm | 1044 mm |
| Bottom Bracket Drop | 75 mm | 72 mm | 72 mm | 72 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 703 mm | 720 mm | 741 mm | 762 mm | 787 mm | 810 mm | 831 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Section Aluminum 105 belongs to the Norco Section model. There are 36 bikes that carry this model name. You can easily view all of the Norco Section bikes models from 2019, here.
Model range prices
Norco Section Aluminum Tiagra Women 2019 is the most economical model, with a starting price of 1399$. Norco Section Carbon Ultegra SL 2019 on the other hand costs 4449$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel bikes average price
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Norco Section Aluminum 105 price was 1849$. Comparing the average cost of a Gravel bike to this one, you will see that Section Aluminum 105 price is 33.15% lower.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The wheels on Section Aluminum 105 are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Section Aluminum 105 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
