Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 27.5" -
Travel Front 200mm -
Travel Rear 190mm -
Fork RockShox BoXXer Select
-
Groupset GX, Praxis -
Suspension Full -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum Park, 190mm Travel, Ride Aligned™
Suspension Fork
RockShox BoXXer Select RC, Charger, 200mm Travel, 46mm Offset
Rear Shock
RockShox Super Deluxe Coil Ultimate DH, Custom Tune 225x75mm, 400lb/in (S), 450lb/in (M), 500lb/in (L), 550lb/in (XL)
Drivetrain
Rear Derailleur
SRAM GX DH Mid Cage
Shift Levers
SRAM GX 1
Cassette
SRAM CS PG720 DH, 11-25T, 7 Speed
Crank
Praxis Cadet HD, 36T, 165mm
Bottom Bracket
Praxis Sealed Bearing, BSA Threaded
Chain
SRAM PC 1110
Chain Guide
e*thirteen Vario Chain Guide
Wheels
Front Hub
Sealed Bearing, 20x110mm Boost, 6 Bolt
Rear Hub
SRAM MTH-746 Sealed Bearing, 12x148mm Boost, HG, 6 bolt
Rims
e*thirteen LG1 DH 27.5
Tires
Maxxis Assegai 2.5", 3C Maxx Grip/DD/TR
Brakes
Brakes
SRAM Code R, 4 Piston, Metallic Pads
Brake Levers
SRAM Code R
Disk Rotors
SRAM Centerline, 200mm
Cockpit
Stem
Race Face Chester DM, 50mm Length, 35mm Clamp
Handlebar
Norco 6061, 800mm, 25mm Rise
Grips
DMR DeathGrip A20, Thin (S, M), Thick (L, XL)
Headset
FSA #57E Sealed Bearing
Seat
Saddle
WTB Volt 250 Sport
Seatpost
Alloy Double Bolt, 34.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.36 mm | 1.3 mm | 1.25 mm |
| Bottom Bracket Height | 347 mm | 347 mm | 347 mm | 347 mm |
| Front Center | 771 mm | 808 mm | 845 mm | 882 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 130 mm | 130 mm | 130 mm | 130 mm |
| Stack | 598 mm | 611 mm | 625 mm | 638 mm |
| Reach | 419 mm | 449 mm | 479 mm | 509 mm |
| Top Tube Length | 557 mm | 587 mm | 616 mm | 645 mm |
| Seat Tube Angle | 77 ° | 77.3 ° | 77.7 ° | 78 ° |
| Seat Tube Length | 365 mm | 395 mm | 410 mm | 455 mm |
| Head Tube Angle | 63 ° | 63 ° | 63 ° | 63 ° |
| Head Tube Length | 100 mm | 115 mm | 130 mm | 145 mm |
| Chainstay Length | 434 mm | 439 mm | 444 mm | 449 mm |
| Wheelbase | 1205 mm | 1247 mm | 1289 mm | 1331 mm |
| Bottom Bracket Drop | 10 mm | 10 mm | 10 mm | 10 mm |
| Standover Height | 683 mm | 680 mm | 682 mm | 673 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Shore Park is part of the Norco Shore model. 26 bikes variations carry this model name so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Norco Shore 2 2022 is the cheapest bike model and costs 4989$. Norco Shore 1 2022 is the most expensive one and costs 6901$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Downhill bikes average price
According to our math, the average price for a trustworthy Downhill bike is 3391$. However, you could also get a good Downhill bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2022 for 5308$. If we compare this with the average Downhill bike cost we notice that the price is 56.53% higher.
Overview of components
Fork
Norco Shore Park 2022 bike is equipped with the RockShox BoXXer Select fork, and has 200mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Norco Shore Park bike has the RockShox Super Deluxe Coil Ultimate DH model installed, and has a travel of 190mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When leaving the production line, the Shore Park model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Shore Park has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Norco Shore Park bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
