Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 200mm -
Travel Rear 190mm -
Fork RockShox BoXXer Select
-
Groupset GX, Praxis -
Suspension Full -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 166cm
MD
163cm - 175cm
LG
172cm - 184cm
XL
181cm - 192cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum Park, 190mm Travel, UDH, Hangerless Interface Compatible, Ride Aligned™
Suspension Fork
RockShox BoXXer Select RC, Charger, 200mm Travel, 46mm Offset
Rear Shock
RockShox Super Deluxe Coil Ultimate DH, Custom Tune 225x75mm, 400lb/in (S), 450lb/in (M), 500lb/in (L), 550lb/in (XL)
Drivetrain
Rear Derailleur
SRAM GX DH Mid Cage
Shift Levers
SRAM GX 1
Cassette
SRAM CS PG720 DH, 11-25T, 7 Speed
Crank
Praxis Cadet HD, 36T, 165mm
Bottom Bracket
Praxis Sealed Bearing, BSA Threaded
Chain
SRAM PC 1110
Chain Guide
e*thirteen Vario Chain Guide
Wheels
Front Hub
Sealed Bearing, 20x110mm Boost, 6 Bolt
Rear Hub
SRAM MTH-746 Sealed Bearing, 12x148mm Boost, HG, 6 bolt
Rims
e*thirteen LG1 DH 27.5
Tires
Front: Maxxis Assegai 2.5", 3C Maxx Grip/DD/TR, Rear: Maxxis Assegai 2.5", 3C Maxx Grip/DD/TR
Brakes
Brakes
Front: SRAM Code R, 4 Piston, Metallic Pads, Rear: SRAM Code R, 4 Piston, Metallic Pads
Brake Levers
SRAM Code R
Cockpit
Stem
Race Face Chester DM, 50mm Length, 35mm Clamp
Handlebar
Norco 6061, 800mm, 25mm Rise
Grips
DMR DeathGrip A20, Thin (S, M), Thick (L, XL)
Headset
FSA #57E Sealed Bearing
Seat
Saddle
WTB Volt 250 Sport
Seatpost
Alloy Double Bolt, 34.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.36 mm | 1.3 mm | 1.25 mm |
| Bottom Bracket Height | 347 mm | 347 mm | 347 mm | 347 mm |
| Front Center | 771 mm | 808 mm | 845 mm | 882 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 130 mm | 130 mm | 130 mm | 130 mm |
| Stack | 598 mm | 611 mm | 625 mm | 638 mm |
| Reach | 419 mm | 449 mm | 479 mm | 509 mm |
| Top Tube Length | 557 mm | 587 mm | 616 mm | 645 mm |
| Seat Tube Angle | 77 ° | 77.3 ° | 77.7 ° | 78 ° |
| Seat Tube Length | 365 mm | 395 mm | 410 mm | 455 mm |
| Head Tube Angle | 63 ° | 63 ° | 63 ° | 63 ° |
| Head Tube Length | 100 mm | 115 mm | 130 mm | 145 mm |
| Chainstay Length | 434 mm | 439 mm | 444 mm | 449 mm |
| Wheelbase | 1205 mm | 1247 mm | 1289 mm | 1331 mm |
| Bottom Bracket Drop | 10 mm | 10 mm | 10 mm | 10 mm |
| Standover Height | 683 mm | 680 mm | 682 mm | 673 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 154 cm | 163 cm | 172 cm | 181 cm |
| Rider Max Height | 166 cm | 175 cm | 184 cm | 192 cm |
About this model
Shore Park is a Norco Shore model. Norco launched 26 bikes of this model so far. You can easily view all of the Norco Shore bikes models from 2023, here.
Model range prices
Norco Shore 2 2023 is the most affordable bike of this model and has a price of 4599$. On the other hand, Norco Shore 1 2023, is the most expensive and costs 6199$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Downhill bikes
If you want an acceptable Downhill bike you should know that the average price is 3391$. However, you could also get a good Downhill bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5099$. In conclusion, this bike price is 50.37% more expensive than the price of the average Downhill bike.
Overview of components
Fork
The fork installed on this bike is the RockShox BoXXer Select model. The travel on this model is 200mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
From the factory, it comes with the RockShox Super Deluxe Coil Ultimate DH rear shock model, which has a travel of 190mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The wheels on Shore Park are the 27.5″ aluminum type. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Shore Park comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Norco Shore Park bike has 4 sizes, in the range of 154 cm – 192 cm (5.05 ft – 6.3 ft). In short, it won’t be difficult to find the right one for you.
