Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 26" -
Travel Front 140mm -
Travel Rear 140mm -
Fork RockShox Sektor
-
Groupset Deore, SLX -
Suspension Full -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
2013 SIGHT frame (140 mm travel)
Suspension Fork
Sektor TK solo air 140 mm travel 15 mm axle
Rear Shock
Fox Float CTD ( No BV)
Drivetrain
Rear Derailleur
Shimano Deore long cage Shadow (10 speed)
Front Derailleur
Shimano SLX E type chainstay mount FD
Shift Levers
Jagwire LEX housing
Cassette
Shimano HG-62 11-36 10 speed cassette
Crank
Shimano M552 10 speed 42/32/22T
Bottom Bracket
N/A
Chain
SRAM PC 1031
Chain Tensioner
N/A
Pedals
Norco alloy flat pedal Steel insert pins
Wheels
Front Hub
Formula alloy DC 51 w/disc 15 mm axle
Rear Hub
Formula alloy DC 22 rear 135 x 10 with QR axle
Rims
Alex DC25 double wall 25 mm wide rim
Tires
Continental X King 26 x 2.4 wire bead
Brakes
Brakes
Avid Elixer 1 hydraulic disc brake
Brake Levers
G2 CS 180 mm 6 bolt rotor
Disk Rotors
N/A
Cockpit
Stem
Norco trail stem 60 mm XS,SM 70 mm M/L 80 XL
Handlebar
Norco rise bar 740 XS/SM, 760 mm on M/L/XL
Grips
T-One lock on grip
Headset
FSA #57B ( tapered internal ) 1.5" to 1-1/8"
Seat
Saddle
Norco design XC / Trail saddle
Seatpost
Norco alloy 2014 double bolt seatpost 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | - | - | - | - | - |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.478 mm | 1.415 mm | 1.366 mm | 1.318 mm | 1.273 mm |
| Bottom Bracket Height | 340.5 mm | 340.5 mm | 340.5 mm | 340.5 mm | 340.5 mm |
| Front Center | 657 mm | 683 mm | 709 mm | 736 mm | 762 mm |
| Rake | 43 mm | 42 mm | 42 mm | 43 mm | 42 mm |
| Trail | 96 mm | 97 mm | 97 mm | 96 mm | 97 mm |
| Stack | 560 mm | 569 mm | 579 mm | 588 mm | 597 mm |
| Reach | 379 mm | 402 mm | 424 mm | 446 mm | 469 mm |
| Top Tube Length | 540 mm | 565 mm | 590 mm | 615 mm | 640 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 405 mm | 435 mm | 470 mm | 510 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1082 mm | 1108 mm | 1134 mm | 1161 mm | 1187 mm |
| Front Travel | 140 mm | 140 mm | 140 mm | 140 mm | 140 mm |
| Rear Travel | 140 mm | 140 mm | 140 mm | 140 mm | 140 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
About this model
Sight 3 belongs to the Norco Sight model. Norco released 215 bikes variations of this model so far. You can get a glimpse at all models from 2013, by clicking on this link.
Model range prices
Norco Sight 3 2013 is the cheapest bike model and costs 2350$. Norco Sight Killer B-1 2013 is the most expensive one and costs 5135$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Norco Sight 3 price was 2350$. Comparing this to the average Trail bike price, we see that the price is 17.53% smaller.
Sight 3 components
Fork
The Sight 3 comes factory-installed with the RockShox Sektor fork. This has a travel range of 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
From the factory, it comes with the Fox Float CTD ( No BV) rear shock model, which has a travel of 140mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When leaving the production line, the Sight 3 model has 26″ aluminum wheels. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Sight 3 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
