Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 140mm -
Fork RockShox Revelation RC
-
Groupset XT, Deore -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sight 650B aluminum 140mm travel
Suspension Fork
Rockshox Revelation RL solo air 140x15mm
Rear Shock
Rockshox Monarch RL (rebound and lockout) and high volume air can (Shocks with external reservoirs not compatible)
Drivetrain
Rear Derailleur
Shimano XT Shadow Plus
Front Derailleur
Shimano Deore M616 high direct mt
Shift Levers
Jagwire LEX housing
Cassette
Shimano HG-62 11-36T 10sp
Crank
Shimano Deore M615 38/24T
Bottom Bracket
Shimano Deore
Chain
KMC X-10 10sp
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
Shimano 15mm front hub w/center lock
Rear Hub
Shimano Deore 142x12mm rear hub w/center lock
Rims
Sun Inferno 25 double wall
Tires
Maxxis Ardent 650Bx2.25 wire bead
Brakes
Brakes
Shimano Deore BLM506 w/180mm rotor
Brake Levers
Shimano Deore
Disk Rotors
N/A
Cockpit
Stem
Norco short reach 3D forged
Handlebar
Norco double butted 760x25mm rise
Grips
Norco single side lock
Headset
FSA #57 E ( tapered internal ) 1.5" to 1-1/8"""
Seat
Saddle
WTB Volt Sport
Seatpost
KS E-Ten adjustable w/remote 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.45 mm | 1.41 mm | 1.36 mm | 1.33 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm | 339 mm |
| Front Center | 658 mm | 682 mm | 705 mm | 730 mm | 753 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 102 mm | 102 mm | 102 mm | 102 mm | 102 mm |
| Stack | 571 mm | 580 mm | 589 mm | 598 mm | 608 mm |
| Reach | 378 mm | 399 mm | 418 mm | 439 mm | 458 mm |
| Top Tube Length | 532 mm | 559 mm | 585 mm | 612 mm | 639 mm |
| Seat Tube Angle | 75 ° | 74.6 ° | 74.2 ° | 73.9 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 405 mm | 435 mm | 470 mm | 510 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 416 mm | 420 mm | 424 mm | 428 mm | 432 mm |
| Wheelbase | 1074 mm | 1102 mm | 1129 mm | 1158 mm | 1185 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm | 15 mm | 15 mm |
| Standover Height | 742 mm | 736 mm | 736 mm | 731 mm | 731 mm |
| Front Travel | 140 mm | 140 mm | 140 mm | 140 mm | 140 mm |
| Rear Travel | 140 mm | 140 mm | 140 mm | 140 mm | 140 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Sight A 7.1 is part of the Norco Sight model. There are 215 bikes that carry this model name. Check out the entire range from 2015 of this model, by clicking this link.
Model range prices
Norco Sight A 7.2 Forma 2015 is the cheapest bike model and costs 2140$. Norco Sight C 7.1 2015 is the most expensive one and costs 6600$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2015 for 2755$. Comparing the average cost of a Trail bike to this one, you will see that Sight A 7.1 price is 0.25% lower.
Overview of components
Fork
The fork installed on this bike is the RockShox Revelation RC model. The travel on this model is 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The shock that’s installed on this bike is Rockshox Monarch RL (rebound and lockout), with a travel distance of 140mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The Sight A 7.1 2015 bike is equipped with 27.5″ aluminum wheels when leaving the factory. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Sight A 7.1 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Norco Sight A 7.1 comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
