Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 130mm -
Fork RockShox Pike RC
-
Groupset GX Eagle, NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco Sight, Aluminum, 130mm (29") | 140mm (27.5") Travel, Boost 12x148mm TA Dropouts
Suspension Fork
RockShox Pike RC, 150mm (29") | 160mm (27.5") Travel, Boost 15x110mm TA, Charger 2 Damper
Rear Shock
Fox Float DPX2 Performance, 185x55mm
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12 Speed
Front Derailleur
-
Shift Levers
Rear: SRAM NX Eagle, 12 Speed, Front: -
Cassette
SRAM NX Eagle PG-1230, 11-50T, 12 Speed
Crank
Truvativ Decendent 6K DUB, 170mm (XS/S) | 175mm (M/L/XL), 30T
Bottom Bracket
SRAM DUB BB, Threaded BSA 73mm
Chain
SRAM NX Eagle, 12 Speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
DT 370 110x15 sealed bearing disc hub
Rear Hub
DT Swiss 370, Boost 12x148mm
Rims
WTB ST i29 TCS 2.0, 32 Hole, 29mm Internal Width
Spokes
DT Swiss Competition, butted 1.8/1.6/1.8, black, stainless steel with prolock
Tires
Maxxis Minion DHF, 2.5" WT, EXO/TR, Folding
Brakes
Brakes
SRAM Guide R, 4 Piston Hydraulic Disc, SRAM CenterLine 180mm Rotor
Brake Levers
SRAM Guide R
Cockpit
Stem
Alloy 6061 50mm stem 29er, 60mm 650B w/35mm bar bore
Handlebar
Race Face Turbine R 35mm, 800mm, 20mm rise
Grips
SDG Stage 1, Lock-On
Headset
FSA #57 E ( tapered internal ) 1.5” to 1-1/8” black FSA logos
Seat
Saddle
SDG Fly Mtn with chromoly rails
Seatpost
TranzX YSP12JL Stealth Dropper, 80mm (XS) | 100mm (S) | 125mm (M) | 150mm (L/XL) Travel, 31.6mm, 1x Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.35 mm | 1.31 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm |
| Front Center | 736 mm | 762 mm | 788 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 107 mm | 107 mm | 107 mm |
| Stack | 615 mm | 615 mm | 625 mm |
| Reach | 428 mm | 454 mm | 476 mm |
| Top Tube Length | 605 mm | 635 mm | 664 mm |
| Seat Tube Angle | 73.9 ° | 73.5 ° | 73.2 ° |
| Seat Tube Length | 435 mm | 470 mm | 510 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 94 mm | 94 mm | 104 mm |
| Chainstay Length | 431 mm | 436 mm | 441 mm |
| Wheelbase | 1165 mm | 1196 mm | 1227 mm |
| Bottom Bracket Drop | 33 mm | 33 mm | 33 mm |
| Standover Height | 795 mm | 793 mm | 798 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
Sight A1 29 belongs to the Norco Sight model. Norco launched 215 bikes of this model so far. Take a sneak peek at all Norco Sight bikes models from 2019, by clicking here.
Model range prices
Norco Sight A3 Women’s 29 2019 is the cheapest bike model and costs 2899$. Norco Sight C1 29 2019 is the most expensive one and costs 5800$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Norco released this model in 2019, its price was 3799$. Doing a quick comparison, we notice that Sight A1 29 price is 37.55% higher than the average cost of a Trail bike.
Overview of components
Fork
Norco Sight A1 29 2019 bike is equipped with the RockShox Pike RC fork, and has 150mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is Fox Float DPX2 Performance, with a travel distance of 130mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The Sight A1 29 2019 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Sight A1 29 comes in 3 sizes, that range from 165 cm – 198 cm (5.41 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
