Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox Revelation RC
-
Groupset NX, Suntour SR -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sight aluminum 640B 140mm travel XS/SM/M
Suspension Fork
Rockshox Revelation RC 150mm boost 650B
Rear Shock
Rockshox Deluxe RT Trunnion w/Debonair
Drivetrain
Rear Derailleur
SRAM NX 11
Front Derailleur
N/A
Shift Levers
SRAM NX 11
Cassette
SRAM NX 11
Crank
SR Suntour Zeron Boost 32T Cranks w/ steel 1X narrow/wide
Bottom Bracket
SR Suntour (comes with crank)
Chain
SRAM 11 speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Shimano Deore 110x15mm
Rear Hub
Shimano Deore 148x12 boost
Rims
WTB STP I29 650B TCS rim, 29mm inner
Spokes
Shadar stainless steel
Tires
Maxxis Forecaster 650B x2.35 Folding bead
Brakes
Brakes
Shimano BR-MT500 hydraulic disc brake w/180mm rotor
Brake Levers
Shimano MT500
Cockpit
Stem
Alloy 55mm MTB stem with 4 bolt front clamp
Handlebar
Norco 25mm rise 6061 DB alloy 760/780mm, 31.8mm bore
Grips
Ergon GE 10 slim lock on grip
Headset
FSA #57 E ( tapered internal ) 1.5" to 1-1/8"
Seat
Saddle
WTB Women's Deva Mtn
Seatpost
JD Trans X post 100mm XS, S, 125mm M, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.46 mm | 1.41 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm |
| Front Center | 675 mm | 701 mm | 728 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 107 mm | 107 mm | 107 mm |
| Stack | 577 mm | 586 mm | 595 mm |
| Reach | 378 mm | 401 mm | 423 mm |
| Top Tube Length | 529 mm | 559 mm | 589 mm |
| Seat Tube Angle | 75.42 ° | 74.95 ° | 74.5 ° |
| Seat Tube Length | 380 mm | 405 mm | 435 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 417 mm | 422 mm | 427 mm |
| Wheelbase | 1091 mm | 1123 mm | 1154 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm |
| Standover Height | 769 mm | 764 mm | 769 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
Model Overview
Sight A3 Womens belongs to the Norco Sight model. Norco released 215 bikes variations of this model so far. You can easily view all of the Norco Sight bikes models from 2018, here.
Model range prices
Norco Sight A3 Womens 2018 is the most economical model, with a starting price of 2799$. Norco Sight C1 29 2018 on the other hand costs 7199$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2018 and its price was 2799$. Comparing this to the average Trail bike price, we see that the price is 1.34% more expensive.
Sight A3 Womens components
Fork
This bike has the RockShox Revelation RC fork installed. The fork’s travel is 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Norco Sight A3 Womens bike has the Rockshox Deluxe RT Trunnion w/Debonair model installed, and has a travel of 140mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
As for the wheels, Norco Sight A3 Womens 2018, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Sight A3 Womens comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 151 cm – 179 cm (4.95 ft – 5.87 ft). In conclusion, it won’t take much to find one that’s right for you.
