Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox Pike RC
-
Groupset GX, SRAM -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sight aluminum 650B 140 mm travel trail
Suspension Fork
Rockshox Pike RC 150mm travel, Solo Air
Rear Shock
Rockshox Monarch RT w/Debonair (Shocks with external reservoirs not compatible)
Drivetrain
Rear Derailleur
SRAM GX
Front Derailleur
N/A
Shift Levers
Jagwire LEX housing
Cassette
SRAM XG 1150 10-42T
Crank
SRAM S-1000 1x11 w/32T
Bottom Bracket
SRAM BB for 73 mm
Chain
PC 1130
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
Formula DC51 15mm
Rear Hub
SRAM MTH746 142 x 12 w/ XD driver
Rims
Alex DP23 650B 28.5 mm wide w/TRS
Tires
N/A
Brakes
Brakes
Shimano Deore 506 hydraulic disc brake
Brake Levers
Shimano Deore 506
Disk Rotors
Shimano 6 bolt SM-RT56 180 mm rotors
Cockpit
Stem
Alloy MTB stem with 4 bolt front clamp
Handlebar
Norco 1" rise bar 760 mm width, 6061 DB alloy
Grips
Norco single side lock
Headset
Cane Creek 10 Series
Seat
Saddle
WTB Volt Sport
Seatpost
Rockshox Reverb 30.9mm ( non stealth)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.49 mm | 1.44 mm | 1.4 mm | 1.35 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 663 mm | 687 mm | 710 mm | 735 mm | 758 mm |
| Rake | 42 mm | 41 mm | 42 mm | 40 mm | 41 mm |
| Trail | 106 mm | 107 mm | 106 mm | 108 mm | 107 mm |
| Stack | 575 mm | 584 mm | 593 mm | 603 mm | 612 mm |
| Reach | 372 mm | 392 mm | 411 mm | 432 mm | 452 mm |
| Top Tube Length | 534 mm | 561 mm | 587 mm | 614 mm | 641 mm |
| Seat Tube Angle | 74.4 ° | 74 ° | 73.6 ° | 73.3 ° | 72.9 ° |
| Seat Tube Length | 380 mm | 405 mm | 435 mm | 470 mm | 510 mm |
| Head Tube Angle | 66.9 ° | 66.9 ° | 66.9 ° | 66.9 ° | 66.9 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 416 mm | 420 mm | 424 mm | 428 mm | 432 mm |
| Wheelbase | 1079 mm | 1106 mm | 1133 mm | 1161 mm | 1189 mm |
| Bottom Bracket Drop | 10 mm | 10 mm | 10 mm | 10 mm | 10 mm |
| Standover Height | 747 mm | 741 mm | 762 mm | 771 mm | 776 mm |
| Front Travel | 150 mm | 150 mm | 150 mm | 150 mm | 150 mm |
| Rear Travel | 140 mm | 140 mm | 140 mm | 140 mm | 140 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Sight A7.1 is part of the Norco Sight model. 215 bikes variations carry this model name so far. You can get a glimpse at all models from 2016, by clicking on this link.
Model range prices
Norco Sight A7.2 2016 is the cheapest bike model and costs 2515$. Norco Sight C7.1 2016 is the most expensive one and costs 6725$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2016 for 3325$. If we compare this with the average Trail bike cost we notice that the price is 20.38% more expensive.
Overview of components
Fork
This bike has the RockShox Pike RC fork installed. The fork’s travel is 150mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this bike has the Rockshox Monarch RT w/Debonair (Shocks with model, with a travel of 140mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When it comes to wheels, the Sight A7.1 bike is equipped with the 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Sight A7.1 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
The Norco model is also equipped with a dropper post. Therefore, climbing or descending will be a breeze.
