Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 140mm -
Fork Fox Float 32
-
Groupset XT, Deore -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sight 27.5 140 mm travel
Suspension Fork
Fox Float 32 Evolution 27.5 140 x 15 x tapered
Rear Shock
Fox Float CTD Evolution high volume (Shocks with external reservoirs not compatible)
Drivetrain
Rear Derailleur
Shimano XT rear derailleur Shadow Plus direct
Front Derailleur
Shimano Deore seattube direct mount
Shift Levers
Jagwire LEX housing
Cassette
Shimano HG-62 10 speed cassette
Crank
Shimano Deore FC-M615-L 38 / 24T
Bottom Bracket
73 mm threaded BB
Chain
SRAM PC 1031 10 speed chain
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
Shimano 15 mm front hub / center lock
Rear Hub
Shimano Deore 142 x 12 rear hub/center lock
Rims
Sun Inferno 25 Pinned rim ( 650 B)
Tires
Kenda Honey Badger 27.5 x 2.35 DTC Kevlar
Brakes
Brakes
Shimano Deore hydraulic disc brake w/160 rotor
Brake Levers
N/A
Disk Rotors
N/A
Cockpit
Stem
Norco short reach 3D forged
Handlebar
Norco 1" rise bar 740 mm width 6061 alloy"
Grips
Norco lock on grips
Headset
FSA #57 E ( semi integrated ) 1.5" to 1-1/8"""
Seat
Saddle
Norco design trail / XC saddle
Seatpost
Norco 6061 alloy double bolt head 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.45 mm | 1.41 mm | 1.36 mm | 1.33 mm |
| Bottom Bracket Height | 338.5 mm | 338.5 mm | 338.5 mm | 338.5 mm | 338.5 mm |
| Front Center | 662 mm | 687 mm | 707 mm | 731 mm | 753 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 102 mm | 102 mm | 102 mm | 102 mm | 102 mm |
| Stack | 571 mm | 580 mm | 589 mm | 598 mm | 608 mm |
| Reach | 378 mm | 399 mm | 418 mm | 439 mm | 458 mm |
| Top Tube Length | 532 mm | 559 mm | 585 mm | 612 mm | 639 mm |
| Seat Tube Angle | 74.9 ° | 74.6 ° | 74.2 ° | 73.9 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 405 mm | 435 mm | 470 mm | 510 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 416 mm | 420 mm | 424 mm | 428 mm | 432 mm |
| Wheelbase | 1074 mm | 1102 mm | 1129 mm | 1158 mm | 1185 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm | 15 mm | 15 mm |
| Standover Height | 742 mm | 736 mm | 736 mm | 731 mm | 731 mm |
| Front Travel | 140 mm | 140 mm | 140 mm | 140 mm | 140 mm |
| Rear Travel | 140 mm | 140 mm | 140 mm | 140 mm | 140 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Sight Alloy 7.1 is part of the Norco Sight model. 215 bikes variations carry this model name so far. Take a sneak peek at all Norco Sight bikes models from 2014, by clicking here.
Model range prices
Norco Sight Alloy 7.2 2014 is the most affordable bike of this model and has a price of 2409$. On the other hand, Norco Sight Carbon LE 2014, is the most expensive and costs 6850$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Norco released this model in 2014, its price was 3150$. Doing a quick comparison, we notice that Sight Alloy 7.1 price is 14.05% more expensive than the average cost of a Trail bike.
Overview of components
Fork
The Sight Alloy 7.1 comes factory-installed with the Fox Float 32 fork. This has a travel range of 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
From the factory, it comes with the Fox Float CTD Evolution high volume rear shock model, which has a travel of 140mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When it comes to wheels, the Sight Alloy 7.1 bike is equipped with the 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
