Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox Revelation RC
-
Groupset Deore, X5 -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sight 650B carbon 140 mm travel trail
Suspension Fork
Rockshox Revelation RL Solo Air 150mm travel
Rear Shock
Rockshox Monarch RT w/Debonair (Shocks with external reservoirs not compatible)
Drivetrain
Rear Derailleur
Shimano Deore M615 Shadow Plus SGS
Front Derailleur
SRAM X5 high direct mount FD
Shift Levers
Jagwire LEX housing
Cassette
Shimano HG-50 11-36T 10 sp
Crank
Shimano Deore M615 38/24T 2x10 w/bb
Bottom Bracket
N/A
Chain
KMC X-10
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
Shimano Deore 618 15mm
Rear Hub
Shimano Deore 618 142 x 12
Rims
Alex DP23 650B 28.5 mm wide w/TRS
Tires
N/A
Brakes
Brakes
Shimano Acera hydraulic disc brake M396
Brake Levers
Shimano Acera
Disk Rotors
Shimano RT-54 180 mm rotors ( center lock)
Cockpit
Stem
Alloy MTB stem with 4 bolt front clamp
Handlebar
Norco 1" rise bar 760 mm width, 6061 DB alloy
Grips
Norco single side lock
Headset
Cane Creek 10 series tapered (integrated)
Seat
Saddle
WTB Volt Sport
Seatpost
KS E-Ten Integra 30.9mm adj post w / remote stealth
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.43 mm | 1.38 mm | 1.34 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 689 mm | 710 mm | 734 mm | 758 mm |
| Rake | 42 mm | 41 mm | 42 mm | 43 mm |
| Trail | 106 mm | 107 mm | 106 mm | 105 mm |
| Stack | 590 mm | 600 mm | 609 mm | 618 mm |
| Reach | 401 mm | 420 mm | 441 mm | 460 mm |
| Top Tube Length | 569 mm | 595 mm | 622 mm | 649 mm |
| Seat Tube Angle | 74 ° | 73.6 ° | 73.3 ° | 72.9 ° |
| Seat Tube Length | 405 mm | 435 mm | 470 mm | 510 mm |
| Head Tube Angle | 66.9 ° | 66.9 ° | 66.9 ° | 66.9 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 428 mm | 432 mm | 436 mm | 440 mm |
| Wheelbase | 1115 mm | 1141 mm | 1170 mm | 1198 mm |
| Bottom Bracket Drop | 10 mm | 11 mm | 12 mm | 13 mm |
| Standover Height | 762 mm | 761 mm | 775 mm | 787 mm |
| Front Travel | 150 mm | 150 mm | 150 mm | 150 mm |
| Rear Travel | 140 mm | 140 mm | 140 mm | 140 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Sight C7.4 is a Norco Sight model. There are 215 bikes that carry this model name. You can get a glimpse at all models from 2016, by clicking on this link.
Model range prices
Norco Sight A7.2 2016 is the cheapest bike model and costs 2515$. Norco Sight C7.1 2016 is the most expensive one and costs 6725$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3750$. If we compare this with the average Trail bike cost we notice that the price is 35.77% more expensive.
Sight C7.4 components
Fork
This bike has the RockShox Revelation RC fork installed. The fork’s travel is 150mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The shock that’s installed on this bike is Rockshox Monarch RT w/Debonair (Shocks with, with a travel distance of 140mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The Sight C7.4 2016 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The Norco model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
