Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 140mm -
Fork RockShox Revelation RC
-
Groupset X0, X1 -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sight 27.5 carbon 140 mm travel (frame will not accept shocks with external reservoir)
Suspension Fork
Rockshox Revelation RLT 140 mm 15mm
Rear Shock
Fox Float CTD Performance B/V (Shocks with external reservoirs not compatible)
Drivetrain
Rear Derailleur
SRAM X0 1 X-Horizontal rear 11 speed der
Front Derailleur
N/A
Shift Levers
Jagwire LEX housing
Cassette
SRAM XG 1195 10-42 11 speed cassette
Crank
SRAM X1 X Sync hollow forged w/ 32 T PFBB92
Bottom Bracket
Press fit BB92
Chain
SRAM PC XX 1 11 speed chain
Chain Tensioner
N/A
Pedals
SRAM MMX match maker right clamp
Wheels
Front Hub
Formula MTB w/disc 15 mm axle sealed
Rear Hub
DT 350 XX1 rear hub or fit with 1 x 11
Rims
Sun Inferno 25 Pinned rim ( 650 B)
Tires
Maxxis Ardent 27.5 x 2.25 EXO w / kevlar bead
Brakes
Brakes
SRAM Elixer Trail 7 hydraulic 160 mm rotor
Brake Levers
Avid G2 CS 180 mm front 6 bolt rotor
Disk Rotors
N/A
Cockpit
Stem
Race Face Turbine stem in black
Handlebar
Race Face Turbine 760 mm .5 rise
Grips
Ergon GA1 EVO
Headset
FSA Orbit C-40-ACB No.42/ACB integrated
Seat
Saddle
WTB Volt Race with chromoly rails
Seatpost
Rockshox Reverb Stealth seatpost 30.9 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.4 mm | 1.36 mm | 1.32 mm |
| Bottom Bracket Height | 338.5 mm | 338.5 mm | 338.5 mm | 338.5 mm |
| Front Center | 687 mm | 707 mm | 731 mm | 753 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 102 mm | 102 mm | 102 mm | 102 mm |
| Stack | 588 mm | 597 mm | 606 mm | 616 mm |
| Reach | 407 mm | 426 mm | 447 mm | 466 mm |
| Top Tube Length | 567 mm | 593 mm | 620 mm | 647 mm |
| Seat Tube Angle | 74.6 ° | 74.2 ° | 73.9 ° | 73.5 ° |
| Seat Tube Length | 405 mm | 435 mm | 470 mm | 510 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 428 mm | 432 mm | 436 mm | 440 mm |
| Wheelbase | 1110 mm | 1137 mm | 1166 mm | 1193 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm | 15 mm |
| Standover Height | 744 mm | 744 mm | 739 mm | 739 mm |
| Front Travel | 140 mm | 140 mm | 140 mm | 140 mm |
| Rear Travel | 140 mm | 140 mm | 140 mm | 140 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Sight Carbon 7.1 belongs to the Norco Sight model. 215 bikes variations carry this model name so far. Take a sneak peek at all Norco Sight bikes models from 2014, by clicking here.
Model range prices
Norco Sight Alloy 7.2 2014 is the most economical model, with a starting price of 2409$. Norco Sight Carbon LE 2014 on the other hand costs 6850$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2014 and its price was 5252$. If we compare this with the average Trail bike cost we notice that the price is 90.15% more expensive.
Overview of components
Fork
The fork installed on this bike is the RockShox Revelation RC model. The travel on this model is 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
Norco Sight Carbon 7.1 bike has the Fox Float CTD Performance B/V (Shocks model installed, and has a travel of 140mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
As for the wheels, Norco Sight Carbon 7.1 2014, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Sight Carbon 7.1 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The Norco model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
