Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 140mm -
Fork RockShox Revelation RC
-
Groupset X9, X7 -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sight 27.5 carbon 140 mm travel (frame will not accept shocks with external reservoir)
Suspension Fork
Rockshox Revelation RL Solo Air 140 15 mm axle 650 B fork
Rear Shock
Rockshox Monarch RL (Shocks with external reservoirs not compatible)
Drivetrain
Rear Derailleur
SRAM X-9 type 2 Rear Derailleur
Front Derailleur
SRAM X-7 10 speed
Shift Levers
Jagwire LEX housing
Cassette
SRAM PG 1030 11-36T 10 speed cassette
Crank
SRAM S-1000 38/24T PF BB92
Bottom Bracket
Comes with crank
Chain
SRAM PC 1031 10 speed chain
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
Formula alloy MTB w/disc 15 mm axle
Rear Hub
Formula DHT 142 alloy rear 142x12 w/sealed
Rims
Sun Inferno 25 Pinned rim ( 650 B)
Tires
Maxxis Ardent 27.5 x 2.25 wire bead
Brakes
Brakes
Formula C1 hydraulic disc brake 160 mm rotor
Brake Levers
Formula speed lock hose fitting at caliper
Disk Rotors
N/A
Cockpit
Stem
Race Face Ride stem
Handlebar
Norco 1" rise bar 740 mm width 6061 alloy"
Grips
T-One lock on grips
Headset
FSA Orbit C-40-ACB No.42/ACB integrated
Seat
Saddle
Norco design trail / XC saddle
Seatpost
X-Fusion hi low adjustable with remote lever 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.4 mm | 1.36 mm | 1.32 mm |
| Bottom Bracket Height | 338.5 mm | 338.5 mm | 338.5 mm | 338.5 mm |
| Front Center | 687 mm | 707 mm | 731 mm | 753 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 102 mm | 102 mm | 102 mm | 102 mm |
| Stack | 588 mm | 597 mm | 606 mm | 616 mm |
| Reach | 407 mm | 426 mm | 447 mm | 466 mm |
| Top Tube Length | 567 mm | 593 mm | 620 mm | 647 mm |
| Seat Tube Angle | 74.6 ° | 74.2 ° | 73.9 ° | 73.5 ° |
| Seat Tube Length | 405 mm | 435 mm | 470 mm | 510 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 428 mm | 432 mm | 436 mm | 440 mm |
| Wheelbase | 1110 mm | 1137 mm | 1166 mm | 1193 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm | 15 mm |
| Standover Height | 744 mm | 744 mm | 739 mm | 739 mm |
| Front Travel | 140 mm | 140 mm | 140 mm | 140 mm |
| Rear Travel | 140 mm | 140 mm | 140 mm | 140 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Sight Carbon 7.2 belongs to the Norco Sight model. Norco launched 215 bikes of this model so far. Check out the entire range from 2014 of this model, by clicking this link.
Model range prices
Norco Sight Alloy 7.2 2014 is the most economical model, with a starting price of 2409$. Norco Sight Carbon LE 2014 on the other hand costs 6850$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3545$. Doing a quick comparison, we notice that Sight Carbon 7.2 price is 28.35% higher than the average cost of a Trail bike.
Sight Carbon 7.2 components
Fork
The Sight Carbon 7.2 comes factory-installed with the RockShox Revelation RC fork. This has a travel range of 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The shock that’s installed on this bike is Rockshox Monarch RL (Shocks with external reservoirs not compatible), with a travel distance of 140mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The Sight Carbon 7.2 2014 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Norco Sight Carbon 7.2 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
