Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 140mm -
Suspension Full
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sight 27.5 ( 650B) 140 mm travel
Rear Shock
Fox Float Factory CTD air shock with adjustable Boost Valve, XV "high volume" (7.875" x 2.25") (200 x 57 mm)
Cockpit
Headset
FSA #57 E ( tapered internal ) 1.5" to 1-1/8"
Seat
Seatpost
Rockshox Reverb post (with remote) , 30.9 mm, 125 mm adjustment travel. XS and SM with 380 mm length, Med , LG and XL with 420 mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | - | - | - | - | - |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.45 mm | 1.41 mm | 1.37 mm | 1.33 mm |
| Bottom Bracket Height | 338.5 mm | 338.5 mm | 338.5 mm | 338.5 mm | 338.5 mm |
| Front Center | 662 mm | 687 mm | 707 mm | 731 mm | 753 mm |
| Rake | 37 mm | 36 mm | 37 mm | 36 mm | 36 mm |
| Trail | 107 mm | 108 mm | 107 mm | 108 mm | 108 mm |
| Stack | 578 mm | 588 mm | 597 mm | 606 mm | 615 mm |
| Reach | 385 mm | 406 mm | 422 mm | 442 mm | 461 mm |
| Top Tube Length | 542 mm | 569 mm | 592 mm | 618 mm | 644 mm |
| Seat Tube Angle | 74.9 ° | 74.6 ° | 74.2 ° | 73.9 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 405 mm | 435 mm | 470 mm | 510 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 416 mm | 420 mm | 424 mm | 428 mm | 432 mm |
| Wheelbase | 1078 mm | 1106 mm | 1131 mm | 1158 mm | 1185 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm | 15 mm | 15 mm |
| Front Travel | 140 mm | 140 mm | 140 mm | 140 mm | 140 mm |
| Rear Travel | 140 mm | 140 mm | 140 mm | 140 mm | 140 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
Model Overview
Sight Killer B 1 Framekit is part of the Norco Sight model. Norco launched 215 frames of this model so far. Take a sneak peek at all Norco Sight frames models from 2013, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail frames
According to our calculations, the average cost of a Trail frame that is reliable is 1736$. However, you could also get a good Trail frame even if you pay a lower amount than the average price. In short, before purchasing your ideal frame do some research about its components, and also check for reviews online.
Sight Killer B 1 Framekit components
Rear Shock
As for the rear shock, this frame has the Fox Float Factory CTD air shock with adjustable Boost Valve model, with a travel of 140mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Dropper post
Norco Sight Killer B 1 Framekit comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
