Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox Yari RC
-
Groupset NX, SRAM -
Suspension Full -
Motor Shimano 250W 60Nm mid-drive -
Battery In-Tube Battery, 500Wh Capacity -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
LG
158cm - 170cm
SM
168cm - 179cm
MD
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco Sight VLT, Carbon, 150mm Travel, Boost 12x148mm Dropouts, Shimano Motor Mount
Suspension Fork
RockShox Yari RC, 160mm Travel, Boost 15x110mm TA, Motion Control Damper, E-Bike Rated, 46mm Offset
Rear Shock
RockShox Deluxe RT, 185x55mm, DebonAir
Drivetrain
Rear Derailleur
SRAM NX, 11 Speed
Front Derailleur
None
Shift Levers
SRAM S-700, Single Click for E-MTB, 11 Speed
Cassette
SRAM NX PG-1130, 11-42T, 11 Speed
Crank
Samox ET-38B, 165mm, Narrow/Wide Chainring 32T, Boost Chainline
Chain
SRAM NX PC-1110, 11 Speed
Chain Guide
None
Pedals
VP Aluminum MTB Flat
Wheels
Front Hub
Shimano Deore HB-M6010, Boost 15x110mm
Rear Hub
Shimano Deore FH-M6010, Boost 12x148mm
Rims
WTB ST i29 TCS 2.0, 32 Hole, 29mm Internal Width
Spokes
Sapim Race, stainless steel, brass nipples
Tires
Maxxis Minion DHF, 27.5x2.6", EXO/TR, Folding
Brakes
Brakes
SRAM Guide T, 4 Piston Hydraulic Disc, SRAM CenterLine 200mm Rotor
Brake Levers
SRAM Guide T
Cockpit
Stem
6061 Aluminum, 50mm Length, 31.8mm Clamp Diameter
Handlebar
6061 Aluminum, 780mm Wide, 25mm Rise, 31.8mm Diameter
Grips
VP, Lock-On
Headset
FSA Orbit 1.5 ZS No.57 HBS, Zero Stack Internal
Seat
Saddle
WTB Volt Sport
Seatpost
TranzX YSP18JL Stealth Dropper, 100mm (S) | 125mm (M) | 130mm (L) Travel, 31.6mm, 2x Lever
Motor & Battery
Motor
Shimano STEPS E7000
Battery
In-Tube Battery, 500Wh Capacity
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | LG | SM | MD |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.45 mm | 1.38 mm | 1.31 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm | 345 mm |
| Front Center | 710 mm | 710 mm | 744 mm | 778 mm |
| Rake | 37 mm | 37 mm | 37 mm | 37 mm |
| Trail | 118 mm | 118 mm | 118 mm | 118 mm |
| Stack | 603 mm | 603 mm | 612 mm | 622 mm |
| Reach | 415 mm | 415 mm | 445 mm | 475 mm |
| Top Tube Length | 575 mm | 575 mm | 608 mm | 640 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 405 mm | 405 mm | 435 mm | 470 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1155 mm | 1155 mm | 1189 mm | 1223 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm | 15 mm |
| Standover Height | 813 mm | 813 mm | 804 mm | 806 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 170 cm | 179 cm | 187 cm |
Model Overview
Sight VLT 3 completes the Norco E Sight model. Norco launched 27 e-bikes of this model so far. You can easily view all of the Norco E Sight e-bikes models from 2019, here.
Model range prices
Norco Sight VLT 3 2019 is the most economical model, with a starting price of 5399$. Norco Sight VLT 1 2019 on the other hand costs 7899$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Enduro e-bikes average price
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2019 for 5399$. Comparing the average cost of an Enduro e-bike to this one, you will see that Sight VLT 3 price is 12.83% more expensive.
Sight VLT 3 components
Fork
This e-bike has the RockShox Yari RC fork installed. The fork’s travel is 160mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The shock that’s installed on this e-bike is RockShox Deluxe RT, with a travel distance of 150mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The Sight VLT 3 2019 e-bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Sight VLT 3 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Sight VLT 3 comes in 4 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
