Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 160mm -
Travel Rear 150mm -
Fork Fox Factory Float 36
-
Groupset X01 Eagle, GX Eagle -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Removable. 900Wh, 720Wh and 540Wh Options. -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 166cm
MD
163cm - 175cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Front Triangle and Seatstay, Aluminum Chainstay, 150mm Travel, UDH, Hangerless Interface Compatible, Ride Aligned™
Suspension Fork
Fox Factory FLOAT 36, GRIP 2, HSC/LSC, HSR/LSR, 160mm Travel, 44mm Offset, E-Rated
Rear Shock
Fox Factory FLOAT X2, Custom Tune, 210x55mm
Drivetrain
Rear Derailleur
SRAM XO1 Eagle
Shift Levers
SRAM GX Eagle Single Click
Cassette
SRAM Eagle XG 1275, 10-52T
Crank
Shimano FC-M8150 E-MTB, 34T Eagle Ring, 165mm
Chain
SRAM GX Eagle
Wheels
Front Hub
DT Swiss 350H 15x110mm Boost, 6 Bolt
Rear Hub
DT Swiss 350H 12x148mm Boost, XD, 6 Bolt
Rims
DT Swiss E 1700 Hybrid E-Rated Wheelset, 29"
Tires
Front: Maxxis Assegai 2.5" 3C MaxxGrip/DD/TR/WT, Rear: Maxxis Assegai 2.5" 3C MaxxGrip/DD/TR/WT
Brakes
Brakes
Front: SRAM Code RSC, 4 Piston, Metallic Pads, Rear: SRAM Code RSC, 4 Piston, Metallic Pads
Brake Levers
SRAM Code RSC
Cockpit
Stem
CNC Alloy, 40mm Length, 35mm Clamp
Handlebar
Deity Skywire Carbon 35, 800mm, 25mm Rise
Grips
DMR DeathGrip A20 Soft, Thin (S, M), Thick (L, XL)
Headset
FSA No.55R-1 Sealed Bearing
Seat
Saddle
Ergon SM-10 E-Mountain Sport
Seatpost
OneUp Adjustable Dropper, 34.9mm, 120mm (S), 150mm (M), 170mm (L) , 210mm (XL)
Motor & Battery
Motor
Shimano STEPS EP8
Battery
Removable. 900Wh, 720Wh and 540Wh Options.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.38 mm | 1.31 mm | 1.25 mm |
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm | 350 mm |
| Front Center | 763 mm | 797 mm | 831 mm | 866 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 134 mm | 134 mm | 134 mm | 134 mm |
| Stack | 611 mm | 620 mm | 629 mm | 638 mm |
| Reach | 420 mm | 450 mm | 480 mm | 510 mm |
| Top Tube Length | 562 mm | 591 mm | 619 mm | 647 mm |
| Seat Tube Angle | 77 ° | 77.3 ° | 77.7 ° | 78 ° |
| Seat Tube Length | 395 mm | 415 mm | 440 mm | 455 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 457 mm | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1219 mm | 1253 mm | 1287 mm | 1322 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 695 mm | 698 mm | 715 mm | 726 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 163 cm | 172 cm | 181 cm |
| Rider Max Height | 166 cm | 175 cm | 184 cm | 191 cm |
About this model
Sight VLT C1 completes the Norco E Sight model. Norco released 27 e-bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Norco Sight VLT A2 2023 is the most affordable e-bike of this model and has a price of 4658$. On the other hand, Norco Sight VLT C1 2023, is the most expensive and costs 8098$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro e-bikes
If you want to purchase a solid Enduro e-bike, it is important to know that the average cost is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 8098$. Comparing the average cost of an Enduro e-bike to this one, you will see that Sight VLT C1 price is 69.24% higher.
Overview of components
Fork
The fork installed on this bike is the Fox Factory Float 36 model. The travel on this model is 160mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Norco Sight VLT C1 e-bike has the Fox Factory FLOAT X2 model installed, and has a travel of 150mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
As for the wheels, Norco Sight VLT C1 2023, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Sight VLT C1 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 154 cm – 191 cm (5.05 ft – 6.27 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Norco Sight VLT C1 comes with a dropper post. Therefore, climbing or descending will be a breeze.
