Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCM HLO
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XXS
137cm - 147cm
XS
146cm - 156cm
SM
154cm - 165cm
MD
163cm - 174cm
MD
174cm - 183cm
LG
172cm - 182cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy, Internal Routing, Smooth Welds
Suspension Fork
Suntour XCM HLO DS, 100mm Travel, 42mm Offset (27.5), 46mm Offset (29)
Drivetrain
Rear Derailleur
Shimano Deore RD-M5100
Shift Levers
Shimano Deore SL-M5100
Cassette
Shimano Deore CS-M5100, 11-51T, 11 Speed
Crank
Shimano Deore FC-M5100-1, 30T, 170mm (XXS, XS, S), 175mm (M, L, XL)
Bottom Bracket
Shimano Cartridge Bearing, BSA Threaded
Chain
KMC X11
Pedals
VP Nylon Flat
Wheels
Front Hub
Alloy QR, 9x100mm QR, 6 Bolt
Rear Hub
Alloy QR, 10x135mm QR, HG, 6 Bolt
Rims
Alex DP21 TRS
Tires
Maxxis Rekon DK60 2.25"
Brakes
Brakes
Tektro HD-M275 Hydraulic, Resin Pads
Brake Levers
Tektro HD-M275, HD-M276 Short Reach on Step-Thru
Disk Rotors
Tektro 160mm
Cockpit
Stem
Alloy 60mm, 31.8mm Clamp
Handlebar
X6 Alloy, 720mm (XXS, XS, S), 740mm (M, L, XL), 25mm Rise
Grips
VP Lock-On
Headset
Zero Stack
Seat
Saddle
Norco XC
Seatpost
TranzX YSP18 Dropper, 130mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | MD | LG | XL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.79 mm | 1.67 mm | 1.56 mm | 1.46 mm | 1.48 mm | 1.4 mm | 1.33 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 602 mm | 636 mm | 326 mm | 703 mm | 703 mm | 737 mm | 771 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 51 mm | 51 mm | 51 mm |
| Trail | 98 mm | 98 mm | 98 mm | 98 mm | 92 mm | 92 mm | 92 mm |
| Stack | 583 mm | 593 mm | 602 mm | 606 mm | 615 mm | 624 mm | 634 mm |
| Reach | 326 mm | 356 mm | 386 mm | 416 mm | 416 mm | 446 mm | 476 mm |
| Top Tube Length | 485 mm | 517 mm | 550 mm | 581 mm | 583 mm | 616 mm | 648 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 340 mm | 390 mm | 430 mm | 470 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1023 mm | 1057 mm | mm | 1125 mm | 1137 mm | 1171 mm | 1205 mm |
| Bottom Bracket Drop | 49 mm | 49 mm | 49 mm | 44 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 579 mm | 607 mm | 623 mm | 664 mm | 677 mm | 712 mm | 745 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 137 cm | 146 cm | 154 cm | 163 cm | 174 cm | 172 cm | 181 cm |
| Rider Max Height | 147 cm | 156 cm | 165 cm | 174 cm | 183 cm | 182 cm | 191 cm |
About this model
Storm 1 27.5 is part of the Norco Storm model. There are 177 bikes that carry this model name. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Norco Storm 2.3 2021 is the most economical model, with a starting price of 479$. Norco Storm 1 27.5 2021 on the other hand costs 1149$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2021 and its price was 1149$. Doing a quick comparison, we notice that Storm 1 27.5 price is 65.8% smaller than the average cost of a Crosscountry bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
Norco Storm 1 27.5 2021 bike is equipped with the SunTour XCM HLO fork, and has 100mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The Storm 1 27.5 2021 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Storm 1 27.5 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 7 sizes available for this model. Rider height can be anywhere between 137 cm – 191 cm (4.49 ft – 6.27 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Norco Storm 1 27.5 comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
