Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 20" -
Travel Front 40mm -
Fork SunTour XCT
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 1 × 6 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco Storm 20", Aluminum, 9x135mm QR Dropouts, Lightweight/Low Standover Height
Suspension Fork
SR Suntour XCT JR 20, 40mm Travel, 9x100mm QR, Coil Spring
Drivetrain
Rear Derailleur
Shimano RD TZ 50 direct mount type
Shift Levers
Shimano SL-RS36, RevoShift, 6 Speed
Cassette
Shimano MF-TZ20, 14-28T, 6 Speed
Crank
Samox 3-Piece Aluminum, 140mm, Narrow/Wide Chainring 30T
Bottom Bracket
Cartridge BB, Square Taper
Chain
KMC Z50, 7 Speed
Pedals
Resin black Jr. flat pedal 9/16" w/bearing
Wheels
Front Hub
KT 36H MTB hub w/ball bearing
Rear Hub
KT, 36 Hole, 10x135mm QR
Rims
Aluminum, 28 Hole, MTB
Tires
20x2.125" with MTB tread
Brakes
Brakes
Tektro 837AL, V-Brake
Brake Levers
Tektro Junior Alloy Levers
Cockpit
Stem
Kalloy 35mm ext. 1-1/8" threadless MTB
Handlebar
Jr. MTB aluminum 600mm wide x 30mm rise
Grips
Jr. MTB Type, Soft Krayton Rubber
Headset
Threadless 1-1/8" ball bearing type
Seat
Saddle
Norco Jr. MTB saddle with cutaway design
Seatpost
Aluminum, Micro Adjust Top, 250mm Long, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.36 mm |
| Bottom Bracket Height | 245 mm |
| Front Center | 521 mm |
| Rake | 40 mm |
| Stack | 431 mm |
| Reach | 317 mm |
| Top Tube Length | 465 mm |
| Seat Tube Angle | 71 ° |
| Seat Tube Length | 230 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 100 mm |
| Chainstay Length | 356 mm |
| Wheelbase | 877 mm |
| Bottom Bracket Drop | 10 mm |
| Standover Height | 547 mm |
| Front Travel | 40 mm |
| Wheels | 20" |
About this model
Storm 2.2 completes the Norco Storm model. 177 bikes variations carry this model name so far. You can get a glimpse at all models from 2018, by clicking on this link.
Model range prices
Norco Storm 2.3 2018 is the most affordable bike of this model and has a price of 269$. On the other hand, Norco Storm 1 29 2018, is the most expensive and costs 729$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Mountain bikes average price
If you want an acceptable Mountain bike you should know that the average price is 616$. However, you could also get a good Mountain bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2018 and its price was 359$. If we compare this with the average Mountain bike cost we notice that the price is 71.59% smaller.
Overview of components
Fork
The SunTour XCT is included from the factory. It has a travel distance of 40mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When leaving the production line, the Storm 2.2 model has 20″ aluminum wheels. The 20″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Storm 2.2 comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
