Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XXS
145cm - 159cm
XS
157cm - 168cm
SM
165cm - 176cm
MD
174cm - 183cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Storm 6061 Alloy XC Frame
Suspension Fork
SR Suntour XCE28, 100mm Travel
Drivetrain
Rear Derailleur
Shimano Tourney RD-TX800
Front Derailleur
Shimano Tourney FD-TX710
Shift Levers
Rear: Shimano EZ FIRE 500, 8 speed, Front: Shimano EZ FIRE 500, 3 speed
Cassette
CS-M5008 11/34T
Crank
Shimano TY301 42/34/24T
Bottom Bracket
Cartridge
Chain
KMC Z7
Pedals
VP Flat Nylon
Wheels
Front Hub
Joytech D871DSE Alloy
Rear Hub
Joytech D872TSE Alloy
Rims
Alex DP21 TRS 29"/27.5"
Tires
WTB Starflight 2.25”
Brakes
Brakes
Tektro MD-280 Mechanical Disc, 160mm
Cockpit
Stem
Norco Alloy 60mm
Handlebar
X6 Alloy, 740mm, 25mm Rise, 31.8mm Bore
Grips
Norco
Headset
Zero Stack
Seat
Saddle
Norco XC
Seatpost
Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD |
|---|---|---|---|---|
| Stack Reach Ratio | 1.79 mm | 1.67 mm | 1.56 mm | 1.46 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm | 310 mm |
| Front Center | 602 mm | 636 mm | 670 mm | 703 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 98 mm | 98 mm | 98 mm | 98 mm |
| Stack | 583 mm | 593 mm | 602 mm | 606 mm |
| Reach | 326 mm | 356 mm | 386 mm | 416 mm |
| Top Tube Length | 485 mm | 517 mm | 550 mm | 581 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 340 mm | 390 mm | 430 mm | 470 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1023 mm | 1057 mm | 1091 mm | 1125 mm |
| Bottom Bracket Drop | 49 mm | 49 mm | 49 mm | 44 mm |
| Standover Height | 579 mm | 607 mm | 623 mm | 664 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 145 cm | 157 cm | 165 cm | 174 cm |
| Rider Max Height | 159 cm | 168 cm | 176 cm | 183 cm |
About this model
Storm 4 27.5 is a Norco Storm model. 177 bikes variations carry this model name so far. You can easily view all of the Norco Storm bikes models from 2020, here.
Model range prices
Norco Storm 2.3 2020 is the most affordable bike of this model and has a price of 349$. On the other hand, Norco Storm 1 29 2020, is the most expensive and costs 949$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 519$. In conclusion, this bike price is 267.05% smaller than the price of the average Crosscountry bike.
Overview of components
Fork
The fork installed on this bike is the SunTour model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The Storm 4 27.5 2020 bike is equipped with 27.5″ aluminum wheels when leaving the factory. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Storm 4 27.5 is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 145 cm – 183 cm (4.76 ft – 6 ft). In conclusion, finding one for you shouldn’t be a problem.
