Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Suntour XCE
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
163cm - 175cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy, Internal Routing, Smooth Welds
Suspension Fork
Suntour XCE28 100mm, 42mm Offset (27.5), 46mm Offset (29)
Drivetrain
Rear Derailleur
Shimano Tourney RD-TX300
Front Derailleur
Shimano Tourney FD-TY500
Shift Levers
Shimano TX ST-EF500
Cassette
CS-M3007, 11-34T, 7 Speed
Crank
Shimano TY301, 42/34/24T, 170mm (XXS, XS, S), 175mm (M, L, XL)
Bottom Bracket
Cartridge, BSA Threaded
Chain
KMC Z7
Pedals
VP Nylon Flat
Wheels
Front Hub
Alloy QR, 9x100mm QR, 6 Bolt
Rear Hub
Alloy QR, 10x135mm QR, HG, 6 Bolt
Rims
WTB SX19
Tires
Front: WTB Starflight 2.25", Rear: WTB Starflight 2.25"
Brakes
Brakes
Front: Tektro HD-M275 Hydraulic, Resin Pads, Rear: Tektro HD-M275 Hydraulic, Resin Pads
Brake Levers
Tektro HD-M275, HD-M276 Short Reach on Step-Thru
Cockpit
Stem
Alloy 60mm, 31.8mm Clamp
Handlebar
X6 Alloy, 720mm (XXS, XS, S), 740mm (M, L, XL), 25mm Rise
Grips
Norco
Headset
Zero Stack
Seat
Saddle
Norco XC
Seatpost
Alloy 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.39 mm | 1.32 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm |
| Front Center | 703 mm | 703 mm | 771 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 92 mm | 92 mm | 92 mm |
| Stack | 626 mm | 635 mm | 645 mm |
| Reach | 427 mm | 457 mm | 487 mm |
| Top Tube Length | 594 mm | 594 mm | 659 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 470 mm | 470 mm | 550 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 105 mm | 105 mm | 125 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm |
| Wheelbase | 1148 mm | 1148 mm | 1216 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm |
| Standover Height | 688 mm | 688 mm | 756 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 163 cm | 172 cm | 181 cm |
| Rider Max Height | 175 cm | 184 cm | 191 cm |
About this model
Storm 4 29 is part of the Norco Storm model. Norco launched 177 bikes of this model so far. You can easily view all of the Norco Storm bikes models from 2022, here.
Model range prices
Norco Storm 2.1 2022 is the most affordable bike of this model and has a price of 381$. On the other hand, Norco Storm 1 27.5 2022, is the most expensive and costs 1199$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Norco released this model in 2022, its price was 799$. Comparing the average cost of a Crosscountry bike to this one, you will see that Storm 4 29 price is 138.42% smaller.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
Norco Storm 4 29 2022 bike is equipped with the Suntour XCE fork, and has 100mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
As for the wheels, Norco Storm 4 29 2022, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The Storm 4 29 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Storm 4 29 comes in 3 sizes, that range from 163 cm – 191 cm (5.35 ft – 6.27 ft). In conclusion, you won’t have a problem finding one that suits you.
