Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 63mm -
Fork SunTour
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Storm Alloy 26" XC Step Thru"
Suspension Fork
Suntour M3020 26 63mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tourney RD-TX55
Front Derailleur
Shimano Tourney FD-TX50
Shift Levers
Shift housing
Cassette
Shimano CS-HG20 12-32T 7spd
Crank
Shimano Tourney FC-M131 42/34/24T
Bottom Bracket
Cartridge BB
Chain
KMC Z-50
Chain Tensioner
N/A
Pedals
Black Resin
Wheels
Front Hub
Formula alloy - Black
Rear Hub
Formula cassette alloy
Rims
Norco Alloy DW
Tires
Kenda Komodo 26x2.1
Brakes
Brakes
Tektro 837AL v-brakes
Brake Levers
Shimano Easy-Fire 51 w/2-finger levers
Disk Rotors
N/A
Cockpit
Stem
Alloy 15degree
Handlebar
Steel 30mm riser bar
Grips
Norco Grip
Headset
FSA No. 10P w/15mm conical spacer
Seat
Saddle
Norco Forma Sport
Seatpost
Norco Alloy 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13" | 15" | 17" | 18.5" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.47 mm | 1.44 mm | 1.39 mm |
| Bottom Bracket Height | 302 mm | 302 mm | 302 mm | 302 mm |
| Front Center | 604 mm | 609 mm | 624 mm | 639 mm |
| Rake | 40 mm | 41 mm | 39 mm | 39 mm |
| Trail | 82 mm | 78 mm | 80 mm | 80 mm |
| Stack | 552 mm | 554 mm | 563 mm | 563 mm |
| Reach | 369 mm | 378 mm | 391 mm | 406 mm |
| Top Tube Length | 528 mm | 543 mm | 558 mm | 573 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 330 mm | 381 mm | 432 mm | 470 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 120 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1025 mm | 1030 mm | 1045 mm | 1060 mm |
| Bottom Bracket Drop | 33 mm | 33 mm | 33 mm | 33 mm |
| Standover Height | 680 mm | 669 mm | 670 mm | 670 mm |
| Front Travel | 63 mm | 63 mm | 63 mm | 63 mm |
| Wheels | 26" | 26" | 26" | 26" |
About this model
Storm 6.3 Step Thru is part of the Norco Storm model. There are 177 bikes that carry this model name. You can easily view all of the Norco Storm bikes models from 2015, here.
Model range prices
Norco Storm 6.3 Step Thru 2015 is the most economical model, with a starting price of 399$. Norco Storm 7.1 2015 on the other hand costs 645$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 399$. If we compare this with the average Crosscountry bike cost we notice that the price is 377.44% smaller.
Overview of components
Fork
This bike has the SunTour fork installed. The fork’s travel is 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The wheels on Storm 6.3 Step Thru are the 26″ aluminum type. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they provide less traction than 29″ wheels do.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Storm 6.3 Step Thru has Rim brakes installed. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
